3 ECU-1170 User Manual
Chapter 1 Overview
1.2.2 System
1.2.3 I/O Interfaces
Table 1.2: System
CPU
Rockchip RK3568J Quad-Core Arm Cortex A55 1.4GHz (Up to
1.8GHz)
RAM 4GB LPDDR4 (Up to 8GB)
eMMC 32GB eMMC (up to 128GB)
Extension Storage 1 x NVMe (Optional by customization)
Display 1 x HDMI (Up to 1080p @120Hz and 4096 x 2304 @60Hz)
Real Time Clock Yes
Watchdog Timer Yes
TPM2.0 Optional by customization
Super-Capacitor Optional by customization (5 seconds power hold upon power loss)
LED 6 x LED (1 x power, 5 x programmable LED)
Table 1.3: I/O Interfaces
Serial
8 x isolated RS-485/232, 2000VDC isolation
COM1 COM2 COM3 COM4 COM5 COM6 COM7 COM8
Mode RS-232/485
Speed 50 ~ 115200 bps 1200 ~ 115200 bps
Data bit 5,6,7,8 8
Isolation 2000 VDC
LAN 4 x 10/100/1000Mbps Ethernet
USB 1 x USB2.0 HOST, 1 x USB3.0 HOST (OTG function reserved)
CAN 2 x Isolated CAN2.0B, 2000VDC isolation (20Kbps~1000Kbps)
SD Card 1 x Micro SD Card Slot
Expansion
Slot
1 x Mini-PCIe (full-size) Signal: PCIe for WI-FI (optional USB2.0/SATA by cus-
tomization)
1 x M.2 B-Key (2280) Signal: USB2.0,USB3.0 for LTE or 5G (Optional PCIe for
NVMe by customization)
SIM Card 2 x Nano SIM card slot for redundancy
ADC
2 x AI
0-20mA or 0-10V (jumper optional), Accuracy 1%, sampling rate: 40sps
DI
4 x isolated DI (wet contact)
16 x isolated DI (dry & wet contact)
2000VDC isolation
DO
(LSD, HSD)
4 x Isolated HSD, Source Type, 10-30V, 1A 2 x isolated LSD, Sink Type, 10-
30V, 1A 2000VDC isolation
DO
(Relay
Output)
8 x Isolated relay (Form A): 5A@250VAC; 3A@30VDC
Breakdown voltage: 750VAC
Initial insulation 1G
Ω at 500VDC
Console 1 x RS-232 (RJ-45)
