ECU-1152 User Manual 6
2.4.2 Serial Communication Status Indicator
2.4.3 Ethernet Status Indicator
LED Color Description
TX0 Green Flash, Debug port data being transmitted
RX0 Green Flash, Debug port data being received
TX1 Green Flash, Serial port 1 data being transmitted
RX1 Green Flash, Serial port 1 data being received
TX2 Green Flash, Serial port 2 data being transmitted
RX2 Green Flash, Serial port 2 data being received
TX3 Green Flash, Serial port 3 data being transmitted
RX3 Green Flash, Serial port 3 data being received
TX4 Green Flash, Serial port 4 data being transmitted
RX4 Green Flash, Serial port 4 data being received
TX5 Green Flash, Serial port 5 data being transmitted
RX5 Green Flash, Serial port 5 data being received
TX6 Green Flash, Serial port 6 data being transmitted
RX6 Green Flash, Serial port 6 data being received
LED Color Description
Link1 Orange Lighting, Ethernet not connected
Act1 Green Blinking, Ethernet data being transmitted
Link2 Orange Lighting, Ethernet not connected
Act2 Green Blinking, Ethernet data being transmitted
