19 ECU-1052 User Manual
Chapter 3 Technical Parameters
3.3 Parameter of Cellular Module
3.4 Parameter of I/O Ports
Electrical characteristics of the digital input are in Table 3.4.
The maximum digital output load is 500 mA at 48 V.
Thermal/
shock/ temp.
variation
EN 60068-2-14
Test Nb, -40
°C/+75 °C, 3h/3h, 2 cycles, 3 K/min
Degrees of
protection pro-
vided by
enclosures
EN 60529 IP30
Vibration,
broadband
random
EN 60068-2-64 Spectrum A.3 cat 1, breakpoints A.6 cat 1
Shock EN 60068-2-27 50 m/s2, 11 ms, half sine, 10 in each dir.
Table 3.2: Type Tests and Environmental Conditions
Table 3.3: Technical Parameters of Cellular Module
Parameter Description
Antenna
Connector type: SMA (ANT + DIV)
VSWR: ≤ 3
Efficiency: > 30%
LTE parameters
Support up to non-CA Cat.4 FDD and TDD
Supported modulations: QPSK (DL/UL), 16QAM and 64QAM
Supported FDD bands: B1 (2100), B3 (1800+), B5 (850), B8 (900
GSM)
Supported TDD bands: B34 (TD 2100), B38 (TD 2600), B39 (TD
1900), B40 (TD 2300), B41 (120M) (TD 2500+)
Bandwidth: 1.4 MHz to 20 MHz
Peak bit rates: 300 Mbps (DL), 50 Mbps (UL) @ 2 × 2 MIMO
Power class: Class 3 (23 dBm ± 2 dBm)
WCDMA
parameters
Support 3GPP R8/DC-HSDPA/HSPA+/HSDPA/HSUPA/WCDMA
Supported modulations: QPSK, 16QAM and 64QAM
Supported bands: B1 (2100 MHz), B8 (900 MHz)
Peak bit rates: 42 Mbps (DL), 5.76 Mbps (UL)
Power class: Class 3 (23.5 dBm ± 2 dBm)
Table 3.4: Electrical Characteristics of Digital Input
Logical
1
Status
2
0 Open
1 Short to ISO_GND
