ARK-3520L User Manual 24
2.5.4 Install bottom case
1. Install 9pcs screws of bottom case
2.5.5 Replace CPU thermal Grease Pad
Always use the grease pad provided by Advantech. The P/N of the grease pad is:
To ensure the best thermal performance, it is recommended to replace the thermal
grease for CPU thermal pole each time the top cover is opened.
1. To replace the thermal grease, clean up the CPU thermal pole by using paper
tissue or soft cloth. DO NOT USE any kind of solvent to clean the thermal pole
as this may damage the thermal grease inside the thermal pole.
2. Gently remove one of the protective papers on the grease pad and apply the
grease to the CPU thermal pole. Press onto the grease pad for 30 seconds,
then remove the protective paper gently from the grease pad.
2.5.6 Wide operating temperature support
To make sure the system works well under 0 C or over 40 C, please ensure your
peripherals are i-grade, which support wide temperature operation.
Part Number Description
1990028893N000 Thermal Pad 25x15x0.2mm K=3.4 PSX-D ARK-3520
