ARK-1222 User Manual 2
1.1 Introduction
The ARK-1222 is a DIN-rail intelligent fanless embedded system featuring Intel® X-
series and N-series processors. It comes with Advantech SUSI 5.0 and DeviceOn for
efficient remote system monitoring. With the latest hybrid-core processor design, the
ARK-1222 offers enhanced performance in CPU processing, display capabilities,
security, and I/O flexibility.
1.2 Specifications
Table 1.1: Specifications
Model Name ARK-1222-S5A1 ARK-1222-U0A1 ARK-1222-S8A1
Processor
System
CPU
Intel® Atom®
x7433RE Quad
Core SoC
Intel N97 Quad
Core SoC
Intel i3-N305 8
Core SoC
Frequency 1.50 GHz 2.0 GHz 1.8GHz
Number of Cores 4 4 8
BIOS AMI EFI 256 Mbit
Memory
Technology DDR5 4800 MHz
Max Capacity 16GB (16GB Built-in)
Socket 1x 262-pin SODIMM
Graphics
Chipset Intel® UHD Graphics
HDMI 4096 x 2160 @ 60 Hz
Dual Display HDMI + HDMI
Ethernet
LAN1
10/100/1000/2500 Mbps Intel i226-IT GbE, supports
Wake-on-LAN
LAN2
10/100/1000/2500 Mbps Intel i226-IT GbE, supports
Wake-on-LAN
Audio Interface Realtek ALC888S, High Definition Audio, Mic-in, Line-out
I/O Interface
Serial Ports 4 x RS-232/422/485, with auto flow control
USB Ports 2 x USB 3.2 (Gen2x1), 2 x USB 2.0
GPIO 8-bit Programmable DIO
Optional CAN Bus 2 x DB9 (by optional cables, cannot coexist with iDoor)
Expansion
Mini PCIe
1 x Full-size mPCIe
M.2
1 x M.2 E-Key 2230 (PCIe x1, USB 2) and 1 x M.2 B-Key
2280 (PCIe x2, USB 3), with nano SIM holder
Storage
NVMe 1 x M.2 B-Key 2280
mSATA 1 x Full-size mSATA (*share with mPCIe slot)
Other
Watchdog Timer 255-level timer interval, setup by software
TPM TPM 2.0 (NPCT764AABYX)
Software
Support
Microsoft Windows Windows 10/11 Enterprise
Linux Ubuntu 24.04
Power
Requirement
Power Type ATX/AT
Power Input
Voltage
12 ~ 28 V
DC
Power Adapter AC to DC, 90W (optional)
Power
Consumption
Typical 11.11W 12.95W 14.47W
Max. 29.3W 32.8W 49.08W
