AOM-3821 User Manual 12
B108 VCC POWER +VDD_IN_MXM
B109 VCC POWER +VDD_IN_MXM
B110 GND GND GND
P-Pin C Side I/F AOM-3821 pin out
C1 GND GND GND
C2 GND GND GND
C3 CSI2_D0-/HDMI_RX_D0- HDMI HDMI_RX_D0N
C4 CSI2_D0+/HDMI_RX_D0+ HDMI HDMI_RX_D0P
C5 GND GND GND
C6 CSI2_D1-/HDMI_RX_D1- HDMI HDMI_RX_D1N
C7 CSI2_D1+/HDMI_RX_D1+ HDMI HDMI_RX_D1P
C8 GND GND GND
C9 CSI2_D2-/HDMI_RX_D2- HDMI HDMI_RX_D2N
C10 CSI2_D2+/HDMI_RX_D2+ HDMI HDMI_RX_D2P
C11 GND GND GND
C12 CSI2_D3-/HDMI_RX_CK- HDMI HDMI_RX_CLKN
C13 CSI2_D3+/HDMI_RX_CK+ HDMI HDMI_RX_CLKP
C14 GND GND GND
C15 CSI2_CK-/HDMI_RX_CEC HDMI GPIO3_D1_d/HDMI_RX_CEC
C16 CSI2_CK+/HDMI_RX_HPD HDMI HDMI_RX_HPD
C17 GND GND GND
C18 CSI2_RST# CSI N.C.
C19 CSI2_PWR#/HDMI_RX_DET# HDMI HDMI_RX_DET#
C20 CSI2_MCK CSI N.C.
C21 GND GND GND
C22
I2C_CSI2_DATA/CSI2_TX-/
HDMI_SDA
HDMI HDMI_RX_SDA_M1
C23
I2C_CSI2_CLK/CSI2_TX+/
HDMI_SCL
HDMI HDMI_RX_SCL_M1
C24 GND GND GND
C25 PCIE_SMCLK PCIe I2C8_SCL_M2
C26 PCIE_SMDAT PCIe I2C8_SDA_M2
C27 GPIO3/ADC/PWM GPIO GPIO0_C4_d_GPIO3
C28 GND GND GND
C29 PCIE30_C_TX- PCIe PCIE_C_TX-
C30 PCIE30_C_TX+ PCIe PCIE_C_TX+
C31 GND GND GND
C32 PCIE30_C_RX- PCIe PCIE_C_RX-
C33 PCIE30_C_RX+ PCIe PCIE_C_RX+
C34 GND GND GND
C35 PCIE30_C_CLK- PCIe
PCIE30_PORTCD_REFCLK-
N_IN_B2B
C36 PCIE30_C_CLK+ PCIe
PCIE30_PORTCD_REFCLK-
P_IN_B2B
C37 GND GND GND
C38 PCIE30_C_RST# PCIe PCIE_C_RST#_1V8
C39 PCIE30_C_REQ# PCIe N.C.
Table 2.1: AOM-3821 Pin-out
