7 AOM-3821 User Manual
Chapter 2 H/W Installation
2.2 Pin Definition
Please refer to the 440 Pin RTXe pin definitions as detailed below:
Table 2.1: AOM-3821 Pin-out
A-Pin A Side I/F AOM-3821 pin out
A1 GND GND GND
A2 SD0_CLK SDIO SD0_CLK
A3 SD0_CMD SDIO SD0_CMD
A4 SD0_D0 SDIO SD0_D0
A5 SD0_D1 SDIO SD0_D1
A6 SD0_D2 SDIO SD0_D2
A7 SD0_D3 SDIO SD0_D3
A8 SD0_CD# SDIO SD0_CD#
A9 SD0_VDD_EN SDIO SD0_VDD_EN
A10 SD0_IOPWR SDIO VCCIO_SD_S0
A11 GND GND GND
A12 SD0_WP SDIO N.C.
A13 USB0_D- USB USB0_D-
A14 USB0_D+ USB USB0_D+
A15 GND GND GND
A16 USB3_A_SS_TX- USB USB3_A_SS_TX-
A17 USB3_A_SS_TX+ USB USB3_A_SS_TX+
A18 GND GND GND
A19 USB3_A_SS_RX- USB USB3_A_SS_RX-
A20 USB3_A_SS_RX+ USB USB3_A_SS_RX+
A21 GND GND GND
A22 TYPEC_OTG_VBUSDET USB TYPEC_OTG_VBUSDET
A23 USB1_HOST_PWR_EN USB USB1_HOST_PWR_EN
A24 USB1_HOST_OC# USB USB1_HOST_OC#
A25 USB0_HOST_PWR_EN USB USB0_HOST_PWR_EN
A26 USB0_HOST_OC# USB USB0_HOST_OC#
A27 USB0_OTG_PWR_EN USB USB0_OTG_PWR_EN
A28 USB0_OTG_OC# USB USB0_OTG_OC#
A29 USB0_OTG_ID USB USB0_OTG_ID
A30 USB0_OTG_VBUS_DET USB USB0_OTG_VBUS_DET
A31 GND GND GND
A32 USB0_OTG_D- USB USB0_OTG_D-
A33 USB0_OTG_D+ USB USB0_OTG_D+
A34 GND GND GND
A35 GMAC0_TXD0 GMAC GMAC1_TXD0
A36 GMAC0_TXD1 GMAC GMAC1_TXD1
A37 GMAC0_TXD2 GMAC GMAC1_TXD2
A38 GMAC0_TXD3 GMAC GMAC1_TXD3
A39 GMAC0_TX_CTL GMAC GMAC1_TX_CTL
A40 GMAC0_TXC GMAC GMAC1_TXCLK
A41 GND GND GND
A42 GMAC0_RXD0 GMAC GMAC1_RXD0
A43 GMAC0_RXD1 GMAC GMAC1_RXD1
