UART 2
# echo 587 > /sys/class/gpio/export (UART MODE1)
# echo 588 > /sys/class/gpio/export (UART MODE0)
# echo out > /sys/class/gpio/gpio587/direction
# echo out > /sys/class/gpio/gpio588/direction
# echo 1 > /sys/class/gpio/gpio587/value
# echo 0 > /sys/class/gpio/gpio588/value
# stty -F /dev/ttyHS2 speed 115200 ignbrk -brkint -icrnl -imaxbel -opost -onlcr
-isig -icanon -iexten -echo -echoe -echok -echoctl -echoke
# cat /dev/ttyHS2 &
# echo "Serial Test" > /dev/ttyHS2
# echo -e "123456789-123456789-123456789-123456789-123456789-\r" | tee
/dev/ttyHS2
3.5 GPIO
• ROM-ED92: GPIO1 (6 pins)
• GPIO_A_0: GPIO#549
• GPIO_A_1: GPIO#550
• GPIO_A_2: GPIO#551
• GPIO_A_3: GPIO#552
• GPIO_A_4: GPIO#553
• GPIO_A_6: GPIO#541
GPIO_A_0 and GPIO_A_1 Loopback Test
1. Connect the GPIO_A_0 and GPIO_A_1
2. Export the GPIO interface
# echo 549 > /sys/class/gpio/export
# echo 550 > /sys/class/gpio/export
3. Set the GPIO direction
# echo out > /sys/class/gpio/gpio350/direction
# echo in > /sys/class/gpio/gpio351/direction
4. Set output value and check
# cat /sys/class/gpio/gpio550/value
0
# echo 1 > /sys/class/gpio/gpio549/value
# cat /sys/class/gpio/gpio550/value
1
Chapter 3
Software Functionality
