2.4.3 Debug Port Connection and Setting
AOM-2721 debug port is shared with A-core Console. Please connect the debug
console cable 1700021565-01. Then connect the USB-to-RS232 Cable to your PC
terminal. Connect the cable to COM1 pin header to the nearby the HDMI connector.
Note! The debug cable needs to be purchased separately.
Part Number
Description
1700021565-01
Debug cable 1x4P-1.25/D-SUB 9P(F)
1. AOM-2721 can communicate with a host server using serial cables. Common serial
communication programs such as HyperTerminal, Tera Term or PuTTY can be used in such
applications. The example demonstrated below describes the serial terminal setup using Tera
Term on a Windows host: Open Tera Term on your Windows PC, and select the settings as
shown in figure.
