PWR_BTN#
AA9
PHONE_ON#
JTAG
Contact Name
Contact Acronym
AOM-2721
JTAG_TCK(SWCLK)
N17
QCM_JTAG_TCK
JTAG_TMS(SWDIO)
N19
QCM_JTAG_TMS
JTAG_TDI
P17
QCM_JTAG_TDI
JTAG_TDO(SWO)
R17
QCM_JTAG_TDO
JTAG_nTRST
R19
QCM_JTAG_TRST#
UART
Contact Name
Contact Acronym
AOM-2721
UART_A_RX
A14
UART_A_RX
UART_A_TX
B13
UART_A_TX
UART_A_RTS
C13
UART_A_RTS#
UART_A_CTS
C14
UART_A_CTS#
UART_B_RX
D14
UART_B_RX
UART_B_TX
D13
UART_B_TX
UART_B_RTS
D15
UART_B_RTS#
UART_B_CTS
D16
UART_B_CTS#
UART_C_RX
A22
UART_C_RX
UART_C_TX
B23
UART_C_TX
UART_D_RX
C22
UART_D_RX
UART_D_TX
C23
UART_D_TX
UART_CON_RX
D22
UART_CON_RX
UART_CON_TX
D23
UART_CON_TX
Ethernet / LAN
Contact Name
Contact Acronym
AOM-2721
ETH_A_(R)(G)MII_CRS
E16
NC
ETH_A_(R)(G)MII_COL
F15
NC
ETH_A_(S)(R)(G)MII_TXD0
H15
ETH_A_TX+
ETH_A_(S)(R)(G)MII_TXD1
G15
ETH_A_TX-
ETH_A_(S)(R)(G)MII_TXD2
H16
ETH_A_CLK+
ETH_A_(S)(R)(G)MII_TXD3
G16
ETH_A_CLK-
ETH_A_(R)(G)MII_TX_EN(_ER)
K16
NC
ETH_A_(R)(G)MII_TX_CLK
J15
NC
ETH_A_(S)(R)(G)MII_RXD0
K15
ETH_A_RX+
ETH_A_(S)(R)(G)MII_RXD1
L15
ETH_A_RX-
ETH_A_(R)(G)MII_RXD2
N15
NC
ETH_A_(R)(G)MII_RXD3
P15
NC
ETH_A_(R)(G)MII_RX_ER
L16
NC
ETH_A_(R)(G)MII_RX_DV(_ER)
M15
NC
ETH_A_(R)(G)MII_RX_CLK
R15
NC
ETH_A_SDP
N16
NC
ETH_MDIO
T15
ETH_A_MDIO
ETH_MDC
T16
ETH_A_MDC
ETH_IOPWR
M17
+VREG_QPS_1P8
ETH_B_(R)(G)MII_CRS
D2
NC
ETH_B_(R)(G)MII_COL
E1
NC
ETH_B_(S)(R)(G)MII_TXD0
G1
ETH_B_TXD0
ETH_B_(S)(R)(G)MII_TXD1
F1
ETH_B_TXD1
ETH_B_(S)(R)(G)MII_TXD2
G2
ETH_B_TXD2
ETH_B_(S)(R)(G)MII_TXD3
F2
ETH_B_TXD3
ETH_B_(R)(G)MII_TX_EN(_ER)
J2
ETH_B_TX_CTL
ETH_B_(R)(G)MII_TX_CLK
H1
ETH_B_TXC
ETH_B_(S)(R)(G)MII_RXD0
J1
ETH_B_RXD0
ETH_B_(S)(R)(G)MII_RXD1
K1
ETH_B_RXD1
ETH_B_(R)(G)MII_RXD2
M1
ETH_B_RXD2
ETH_B_(R)(G)MII_RXD3
N1
ETH_B_RXD3
