1.1 Introduction
Advantech's AOM-2721 is powered by Qualcomm QCS6490 SoC which includes up
to Kryo 8 cores up to 2.7GHz in combination with Andreo GPU 643 and Andreo VPU
633 graphics engine. It provides PCIe, USB 3.2, Giga Ethernet, MIPI-CSI, SPI, GPIO,
and HDMI, DP, 2ch. LVDS display for embedded applications.
AOM-2721 is paired with Advantech OSM carrier board for faster end product
peripheral integration and time-to-market. The reference schematics and layout
checklists documentations for carrier board development will be provided along with
Windows 11, Ubuntu, test utilities, hardware design utilities and reference drivers.
1.2 Product Features
Model Name AOM-2721
Form Factor OSM1.1
Processor
System
Memory
Graphics
CPU
QCS6490 Kryo 8 Cores up to 2.7GHz
Technology LPDDR5 up to 6400MT/s
Capacity On-board 8GB
Flash 128 GB eMMC and 128GB UFS for O.S.
HDMI 1 x HDMI 1920x1080 @60Hz (Share 2.ch LVDS port)
LVDS 1 x Dual channel LVDS1920x1080 @60Hz (Share
HDMI port)
DP 1x DP 2lane: 1920x1080 @60Hz
Andreo VPU 633 4K30 encode/Decode
Graphics Engine Andreo GPU 643, OpenGL ES3.2/OpenCL 2.0
Ethernet
Chipset 1 x QPS615 integrated RGMII and SGMII
I/O
Serial Port
2 x 4-wire UART, 2 x 2-wire UART,
1 x 2-wire UART for debug console
SPI 3
CAN-FD -
GPIO 6
SDIO 1 x Micro SD
I2C -
Camera Input 2 x 4-lane MIPI CSI
M.2 slots 1x M.2 Key B Type 3042/3052 slot
1x M.2 Key E Type 2230 slot
Power
Power Supply Voltage 12V
Power Consumption 12.1Watts
Environment
Operational
Temperature
-20 ~ 70 °C
Operating Humidity 5 ~ 95% Relative Humidity, non-condensing
Mechanical Dimensions (W x D x H) 165 x 115 x 25 mm
Operating System Windows 11 IoT Enterprise, Ubuntu
Speed
2 x 10/100/1000 Mbps
RTC
RTC
External RTC
Security
Qualcomm® Trusted Execution Environment (TEE)
v5.3
USB
1 x USB3.2 Gen 1 and 1 x USB2.0
Audio
1 x I2S
Table 1.1: Product Features
