Mode
AIW-356 DQ-N01
LTE
DL peak rate 1.6Gbps (CAT19)
UL peak rate 211Mbps (CAT18)
Support RF bandwidth 1.4MHz–20MHz
Support 3GPP R15, DL 256-QAM, UL 256-QAM
Support max 5DLCA,DL 4×4 MIMO
NR SA
UL peak rate 900 Mbps
DL peak rate 2.47 Gbps
Support DL 256-QAM, UL 256-QAM
Support RF bandwidth 5 MHz–100 MHz
DL 4×4 MIMO,UL 2×2 MIMO
NR NSA
DL peak rate 3.47Gbps
UL peak rate 555Mbps
NR Modulation: DL-256 QAM, UL-256 QAM
NR supports a maximum of 4X4 MIMO in the downlink
Table 2-2 Data throughput
Mode
AIW-356 DQ-N01
LTE
Support max DL 5CA
Support max UL 2CA
Support 3GPP R16
Support DL 256-QAM, UL 256-QAM
Support RF bandwidth 1.4MHz–20MHz
NR Sub6 ENDC
Support max DL LTE 4CA + NR 1CA
Support max DL LTE 4CA + NR 2CA (Reserved)
Support max UL LTE 1CA + NR 1CA (Reserved)
LTE Modulation: DL-256QAM, UL-256QAM
NR Modulation: DL-256QAM, UL-256QAM
NR Sub6 SA
Support max DL 2CA
Support max UL 2CA
Support DL 256QAM, UL 256QAM
Support RF bandwidth 5MHz–100MHz
Sub carrier spacing 15KHz (FDD) and 30KHz (TDD)
SRS
SA: N41 N77 Support 2T4R
NSA: N41 Support 1T2R (n41), IT4R (n77)
Table 2-3 Modulation characteristic
