18
Pin
Pin Name
I/O
Reset
Value
Description
Type
35
USB_SS-RX -
I
-
Negative end of USB super
-
speed data receiving
36
UIM1_PWR
PO
-
SIM card 1 power supply, 3V/1.8V
1.8V/
3V
37
USB_SS-RX+
I
-
Positive end of USB super speed receive
data plus
1.8V
38
NC
-
-
-
-
39
GND
-
-
GND
Power
Supply
40
SIM2_DETECT
I
PU
SIM card 2 detection, internally
1.8V
pulled up through 390KΩ resistor,
Active high by default
41
PETn0
O
-
Negative end of PCIe data TX
-
42
UIM2_DATA
I/O
L
SIM card 2 data
3V/
1.8V
43
PETp0
O
-
Positive end of PCIe data TX
-
44
UIM2_CLK
O
L
SIM card 2 clock
3V/
1.8V
45
GND
-
-
GND
Power
Supply
46
UIM2_RESET
O
L
SIM card 2 reset
3V/
1.8V
47
PERn0
I
-
Negative end of PCIe data RX
-
48
UIM2_PWR
PO
-
SIM card 2 power supply
3V/
1.8V
49
PERp0
I
-
Positive end of PCIe data RX
-
50
PERST#
I
PU
Module PCIe interface reset.
3.3V/
1.8V
Active low, internally pulled up
through 4.7KΩ resistor
51
GND
-
-
GND
Power
Supply
