v AIMB-288E User Manual
M.2 SSD Compatibility
Initial Inspection
Before you begin installing your motherboard, please make sure that the following
materials have been shipped:
1 x AIMB-288E Intel® Core™ i9/i7/i5/i3 (LGA1700) THIN AI motherboard
1 x SATA HDD cable
1-to-2 serial port cables, 22cm
1 x SATA power cable
1 x I/O port bracket
1 x Startup Manual
1 x Warranty Card
If any of these items are missing or damaged, contact your distributor or sales repre-
sentative immediately. We have carefully inspected the AIMB-288E mechanically and
electrically before shipment. It should be free of marks and scratches and in perfect
working order upon receipt. As you unpack the AIMB-288E, check it for signs of ship-
ping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or
it fails to meet the specifications, notify our service department or your local sales
representative immediately. Also notify the carrier. Retain the shipping carton and
packing material for inspection by the carrier. After inspection, we will make arrange-
ments to repair or replace the unit.
Dimension Interface
Bandwidth
Performance
Vendor
Category
Vendor Model ADVANTECH P/N
2280
M.2 B+M
Key
PCIe v3.1
NVMe
PCIe SSD
Advantech SQF-C8BV4-2TDEDC SQF-C8BV4-2TDEDC
2242
M.2 M-
Key
PCIe v3.1
NVMe
PCIe SSD
Advantech SQF-C4MV4-2TDEDC SQF-C4MV4-2TDEDC
2280
M.2 B+M
Key
SATA3 SSD Advantech SQF-SM8V4-1TCSBC SQF-SM8V4-1TCSBC
2280
M.2 M-
Key
PCIe v3.0
NVMe
PCIe SSD
WD
WDSN850500GBP-
CIeM.2SSD
N/A
2260
M.2 B+M
Key
SATA3 SSD Advantech
SQF-SM8V4-1K9GD-
SCC
SQF-SM8V4-1K9GD-
SCC
2280
M.2 B+M
Key
SATA3 SSD Advantech SQF-S8BV4-2TDSDC SQF-S8BV4-2TDSDC
2242
M.2 B+M
Key
SATA3 SSD Advantech
SQF-SM4Z2-
128GCSBE
SQF-SM4Z2-
128GCSBE
2242
M.2 B+M
Key
SATA3 SSD Advantech
SQF-SM4Z2-
128GCSBC
SQF-SM4Z2-
128GCSBC
2280
M.2 B+M
Key
SATA3 SSD Advantech
SQF-SM8Z4-
256GCSBE
SQF-SM8Z4-
256GCSBE
2280
M.2 M-
Key
PCIe v3.1
NVMe
PCIe SSD
Advantech SQF-C8MV4-2TCEDC SQF-C8MV4-2TCEDC
3042
M.2 B-
Key
USB 3.1 Gen1 4G LTE
Sierra
Wireless
EM7455 N/A
