AIMB-279 User Manual 4
1.4 Jumpers and Connectors
Connectors on the AIMB-279 motherboard link it to devices such as hard disk drives
and a keyboard. In addition, the board has a number of jumpers used to configure the
system for your application.
The tables below list the function of each of the board jumpers and connectors. Later
sections in this chapter give instructions on setting jumpers. Chapter 2 gives instruc-
tions for connecting external devices to your motherboard.
Table 1.1: Connector and Header List
Item Description Part Reference
1 DC IN CONNECTOR
DCIN1
DCIN2 (vertical
phoenix connector)
2 RJ-45 + USB 3.2 stack connector (GEN2) Lan1_USB12
3 RJ-45 Lan2
4 USB 3.2 Gen1 x 2 USB34
5 DisplayPort DP2
6 DisplayPort/HDMI dual port stack up connector Dp1+hdmi1
7 HD audio interface (analog) AUDIO1
8 Audio amplifier output pin header AMP1
9 PCI Express x16 slot PCIEX16_1
10 IMVP9.1 programming header VR_PMB1
11 System Fan #1 connector SYSFAN1
12 CPU FAN connector CPUFAN1
13 EDP connector / LVDS connector EDP1_LVDS1
14 LVDS VESA, JEIDA format selection pin header JLVDS_VCON1
15 EDP Panel / LVDS Panel Voltage Selection JEDP1_LVDS1
16 EDP / LVDS backlight inverter power connector INV1
17 AT / ATX mode selection JPSON1
18 8-bit general purpose I/O pin header GPIO1
19 ESPI port 80 connector ESPI_P80
20 COM1 connector (RS232) COM1
21 SATA power SATA_PWR2
22 COM2 connector (RS232/RS422/RS485) COM2
23 SATA power SATA_PWR1
24 PWRBTN#/ RESET#/HDD LED/SMBUS JFP1
25 Power LED pin header JFP2
26 Serial ATA interface connector SATA2
27 Serial ATA interface connector SATA1
28 USB 2.0 wafer USB56
29 RTC / CMOS clear JCMOS1
30 Flash descriptor security override pin header JME1
31 M.2 M-Key connector M2_M1
32 SPI BIOS flash pin header SPI_CN1
33 M.2 E-Key connector M2_E1
34 CMOS battery connector BAT1
35 Case open connector JCASE1
36 COM1 RI# selection pin header JSETCOM1_V1
