AIMB-215 B1 User Manual 4
1.4.6 Industrial Features
Watchdog timer: Can generate a system reset. The watchdog timer is pro-
grammable, with each unit equal to one second or one minute (255 levels)
1.4.7 Mechanical and Environmental Specifications
Operating temperature: 0 ~ 60 °C (32 ~ 140 °F, depending on the CPU)
Storage temperature: -40 ~ 85 °C (-40 ~ 185 °F)
Humidity: 5 ~ 95% non-condensing
Power supply voltage: +12 V
Power consumption:+12 V @ 2.03 A (Intel J1900 2.0 GHz processor/DDR3L
1333 MHz 4 GB x 2)
Board size: 170 x 170 mm (6.69 x 6.69")
Board weight: 0.365 kg
1.5 Jumpers and Connectors
The AIMB-215 B1 motherboard is equipped with connectors for linking the board to
external devices such as hard disk drives and a keyboard. The board also features
several jumpers for configuring the system according to specific applications.
The function of each board jumper and connector is listed in the table below. The pro-
cedure for setting jumpers is explained in subsequent sections of this chapter.
Instructions for connecting external devices to the motherboard are provided in
Chapter 2.
Table 1.1: Connector/Header List
Description Part Reference
1 DC-IN adaptor connector DCIN1
2 Display Port connector DP1
3 eDP panel voltage selection JEDP-1+JEDP-2
4 VGA connector VGA1
5 Serial ATA interface connector SATA2
6 SATADOM power pin header JSATAPWR1
7 Serial ATA interface connector SATA1
8 CMOS battery wafer box BAT1
9 System fan connector SYSFAN2
10 USB 3.0 + USB 2.0 stack connector USB0102
11 SPI BIOS socket SPI1
12 USB 2.0 * 2 stack connector USB0304
13 COM1 box header COM1
14 Watchdog timer output and OBS beep JOBS1+JWDT1
15 RJ45(LAN 1+ LAN 2) connector LAN12
16 SPDIF interface pin header SPDIF_OUT1
17 HD analog audio interface AUDIO1
18 Front-panel audio pin header FPAUD1
19 Audio amplifier output pin header JAMP1
20 PCI-Express p16-x1 slot PCIEX1_1
21
LVDS VESA, JEIDA format selection pin
header
JLVDS_VCON1
