AIIS-1240 User Manual 2
1.1 Introduction
AIIS-1240 Box IPC is an ideal, application-ready, system platform solution. All elec-
tronics are protected in a compact sealed case for easy embedding in the customer’s
own housing, or as a stand-alone unit where space is limited.
AIIS-1240’s self-contained PoE controller features performance computing with
Power over Ethernet, rich I/O interface, and extended product longevity, all in a com-
pact form factor. These PoE boxes use the latest, 3rd generation Intel
®
Core
TM
pro-
cessors to deliver improved computing power and graphics performance. Already
fully verified and certified, they offer system integrators a no-nonsense solution.
AIIS-1240 utilizes a single RJ45 cable that carries both data and electrical power.
Compliant with IEEE 802.3af, it can provide a maximum of 15.4 watts of power to
each powered device up to a distance of 100 meters, whereas USB 2.0 can only pro-
vide up to 2.5 watts, with a maximum cable length of 5 meters.
AIIS-1240 offers rich I/O interfaces such as four PoE port channels, max. 40-bit digi-
tal I/O, four USB 3.0, four USB 2.0, and six serial ports. Four USB 3.0 ports provide a
high performance data transfer rate up to 5 Gbps. The two serial ports on the front
panel can be configured as RS-232, RS-422 or RS-485 via BIOS setting. These
interfaces can support a number of various peripheral devices.
1.2 Product Features
Intel® 3rd/2nd Core™ i7/i5/i3 CPU (LGA1155)
4-CH GbE PoE (Power over Ethernet), IEEE 802.3af compliant
– Powered Device auto detection and classification
– Supports IEEE 1588 & GigE Vision devices
Compact & thoughtful design
– Volume less than 3 Liter
– Easier Fan filter maintenance
– Internal USB Type-A with lock design (Max. 49mm length)
– Wall or DIN Rail mounting kit (optional)
– Build in G-sensor for vibration detection
1.3 Product Specifications
1.3.1 Processor System
LGA1155 Intel® Core™ i7/i5/i3/Pentium®/Celeron
CPU
Core
i7-3770
Core
i7-2600
Core
i5-3550S
Core
i5-2400
Core
i3-3220
Core
i3-2120
Core
G2120
Core
G850
Core
G540
Core 444 422222
Base
Frequency
3.4
GHz
3.4
GHz
3.0
GHz
3.1
GHz
3.3
GHz
3.3
GHz
3.1
GHz
2.9
GHz
2.5
GHz
L3 Cache 8 MB 8 MB 6 MB 6 MB 3 MB 3 MB 3 MB 3 MB 2 MB
Chipset H61
BIOS AMI 64Mb SPI Flash
