AFE-R360DVK-G01 Startup Manual 1
Before you begin installing your board, please make sure
that the following items have been shipped:
1. 1 x AFE-R360C5P-Q5A1 and 1 x MIOe-GMSL-4PA1
pre-assembled
2. 1 x SQR-SD5N16G5K6HNAG, SODIMM DDR5 5600
16GB
3. 1 x SQF-C8BV2-128GDEDC, M.2 2280 128G NVMe,
with preloaded Ubuntu 22.04 image & GMSL camera
driver
4. 4 x oToCAM222 GMSL cameras, 1920x1280 (P/N:
96ICAM-222)
5. 1 x Cooler (P/N: 1970005512T001)
6. 4 x GMSL cables 100cm (P/N: 1751000759-01)
7. 4 x COM RS-232 cables 20cm (P/N: 1700031582-01)
8. 1 x USB 2.0 cable (PN: 1700030406-01)
9. 1 x power Y-cable for AFE-R360 and MIOe-GMSL (P/N:
1700023503-01)
10. 1 x screw kit for M.2 expansions
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
AFE-R360DVK-G01
AFE-R360, 125H, 4 x GMSL (2.5MP) Development
Kit
Startup Manual
Mechanical Assembly (pre-assembled at
the factory)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw
This manual is for the AFE-R360DVK-G01 series Rev.
A1.
Part No. 2046R36010
Printed in China
1st Edition
April 2025
Packing List Mechanical Assembly
