AFE-E630 User Manual iv
Optional Accessories
Safety Instructions
1. Read these safety instructions carefully.
2. Retain this user manual for future reference.
3. Disconnect the equipment from all power outlets before cleaning. Use only a
damp cloth for cleaning. Do not use liquid or spray detergents.
4. For pluggable equipment, the power outlet socket must be located near the
equipment and easily accessible.
5. Protect the equipment from humidity.
6. Place the equipment on a reliable surface during installation. Dropping or letting
the equipment fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. Do not cover the openings.
8. Ensure that the voltage of the power source is correct before connecting the
equipment to a power outlet.
Part Number Description
96PSA-A36W12W7-5 ADP A/D 100-240V 36W 12V C6 LOCK DC JACK 62368
96PSA-A60W24T2-3 ADP A/D 100-240V 60W 24V C14 CORD END 2-pin 62368
1702002605 Power Cord 3P EU 10A 250V 183 cm (72 in)
1702031801 Power Cord 3P UK 10A 250V 183 cm (72 in)
1702002600 Power Cord UL 3P 10A 125V 183 cm (72 in)
1700008921 Power Cord 3P PSE 183 cm (72 in)
1700009652 Power Cord CCC 3P 10A 250V 187 cm (73.6 in)
AIW-344FQ-N01 AIW-3 series LTE CAT4 mini PCIe module for US (QTY *1)
AIW-344FQ-E02
AIW-3 series LTE CAT4 mini PCI-e module for Europe (QTY
*1)
AIW-344FQ-J01 AIW-3 series LTE CAT4 mini PCI-e module for JP (QTY *1)
TBD
Qucetel EC20CEFRSG-MINIPCIE-C 4G module for China
(QTY *1)
1750009372-01
Ant.SMA/M 90/180 5G BLK 167mm RG178 for 4G Antenna
(QTY *2)
1751000361-01 GPS&BEIDOU ANTENNA L=5m for GPS Antenna (QTY *1)
1750008652-01
Cable Ant. SMA/F-BH CI-113/113 BLK 200mm for 4G/GPS
cable (QTY *1)
1750009035-01
Cable Ant. SMA/F-BH MHF1/113 BLK L100mm for 4G cable
(QTY *1)
AIW-162BS-GI1 Industrial grade Wi-Fi 6 M.2 solution (QTY *1)
1751000591-01
Dipole Ant. Wi-Fi 6E SMA/M-R BLK L163.1mm for Wi-Fi 6
Antenna (QTY *2)
1750009360-01
Cable Ant. SMA/F-R-BH MHF4/113 BLK L100mm for Wi-Fi 6
Antenna Cable (QTY *2)
