AFE-E420 User Manual 2
1.1 Introduction
The AFE-E420 is a compact 4" SBC (single board computer) in the 165 x 115 mm
form factor. It’s part of the Compact Series and runs on the NXP® i.MX 93 processor,
featuring a Dual Arm® Cortex-A55 core.
The AFE-E420 supports onboard LPDDR4x-3733 memory up to 2GB, and includes
eMMC storage along with an SD card socket. Display options include either LVDS or
HDMI.
For connectivity and I/O, it offers dual Gigabit Ethernet, three USB ports, six COM
ports, four CAN bus interfaces, two PLC connections, and a 4-channel RTD input.
1.2 Specifications
Table 1.1: Specifications
Platform
Processor NXP i.MX 93 with Dual Arm® Cortex-A55
Max. Frequency 1.70 GHz
Core Dual
Memory
Technology LPDDR4x-3733MT/s
Max. Capacity Up to 2GB
Channel/Socket Single Channel / Onboard LPDDR4x
ECC Support Inline ECC
Display I/F
LCD
1 x LVDS, Single Channel 18-/24-bit, up to 1366 x
768 or 1280 x 800 (*other LVDS panel)
*HDMI
1 x HDMI 1.3, up to 1920 x 1080
(*HDMI support by request)
Display Single Display, LVDS or HDMI
Ethernet
Controller 2 x LAN: Realtek 8211 (PHY)
Speed GbE
External I/O
Ethernet 2 x RJ-45
HDMI *1
USB 2.0 1
Micro-USB 1 (for debug only)
Internal I/O
USB 2.0 2
Serial Bus 2 x I2C
COM Port 6 x RS-232/422/485 (COM5 & COM6 with isolation)
GPIO 16-bit general purpose input output
CAN Bus 4 x CAN-FD (CAN1 & CAN2 with isolation)
Audio NXP SGTL5000, Line-in/Line-out/MIC
Amplifier YES (Stereo, 2.5W)
RTD
4-channel (3-wire), PT1000/PT100 compatible
sampling rate 100Hz
Fan 2 x fans, 12V, 0.3A (4-wire)
Front Panel
Control
Power Button, Reset Button, 5V/3.3V Power Indica-
tor
Power Line
Communication
PLC Controller 2 x QCA7006
Control Pilot Dual ports with PWM & ADC
Storage eMMC 16 GB
