ADAM-5000 Series User Manual 56
6.1 Counter/Frequency Modules
Compatible ADAM-5000 Series Main Units
ADAM-5080 is a 4-channel counter/frequency module designed to be implemented
within the following Advantech ADAM-5000 series main units:
ADAM-5000/485
ADAM-5510
ADAM-5511
ADAM-5510M
ADAM-5510E
ADAM-5510/TCP
ADAM-5510E/TCP
6.1.1 ADAM-5080 4-ch Counter/Frequency Module
With ADAM-5080 4-Channel Counter/Frequency Module, users can select either
counter or frequency mode for data output. ADAM-5080 offers users a variety of very
flexible and versatile applications such as below:
Counter Mode or Frequency Mode
If you wish to quantify input signals for the totalizer function, you can utilize the counter
mode for measurements related to movement and flow quantity. Alternatively, you may
opt for the frequency mode to compute the instantaneous differential of variables like
rotating speed, frequency, or flow rate and display them in specific engineering formats.
Up/Down or Bi-direction Function
When operating in counter mode, you can choose either the Up/Down function or the
Bi-direction function for different application purposes. The counter will count up or
down according to your applications. This counting function helps users obtain the
most accurate data.
Alarm Setting Function
In counter mode, you have the option to set the alarm status to either 'Disable' or
'Latch.' Choosing 'Disable' means the alarm is turned off. Opting for 'Latch' means
the alarm status will be 'latched' when triggered and will remain in that state until a
'Clear Alarm Status' command is issued to return it to normal. Users can define high
and low-limit values to control alarm behavior using the utility program.
Digital Output Mapping
Users can either run the utility program or issue a "Set Alarm Connection" command to
designate a specific digital output module for the alarm signal to be sent through.
Note! Please make sure that the ADAM-5080 counter/frequency module is
properly inserted into the compatible main units.
