ADAM-5000 Series User Manual 12
Figure 1.15 Locations of Jumpers
Note! To maintain measurement accuracy pleases short channels not in use.
Table 1.7: Technical Specifications of ADAM-5017H
Analog Input Channels 8 differential
ADC Resolution 12 bits, plus sign bit
Type of ADC Successive approximation
Isolation Voltage
3000 V
DC
Sampling Rate 100 Hz
Input Impedance
2M (voltage input)
120 (current input)
Signal Input Bandwidth 1000 Hz for both voltage inputs and current inputs
Analog Signal Range ±15 V max.
Analog Signal Range for any
two measured Pins
±15 V max.
Power Requirements
+10 to +30 V
DC
(non-regulated)
Power Consumption 1.8 W
Accuracy
± 0.1% or better Voltage mode
± 0.2% or better Current mode
