2.1 Selecting I/O Module
To organize an ADAM-5000/ECAT I/O system, you need to select I/O modules to
interface the main unit with field devices or processes that you have previously deter-
mined. There are several things should be considered when you select the I/O mod-
ules. What type of I/O signal is applied in your system? How much I/O is required to
your system? How will you place the main unit for concentrate the I/O points of an
entire process.
How many ADAM-5000/ECAT main units are required for distributed I/O points
arrangement.
What is the required voltage range for each I/O module? What isolation environment
is required for each I/O module? What are the noise and distance limitations for each
I/O module? Refer to table 2-1 I/O as module selection guidelines
Advantech provides more than 10 types of ADAM-5000 I/O modules for various
applications so far. The table
2-2 will help you to select the ADAM-5000 I/O modules
quickly and easily.
Table 2.1: I/O Selection Guidelines
Type Application Description
Discrete input
module and block
I/O module
Selector switches, pushbuttons, photo-
electric eyes, limit switches, circuit break-
ers, proximity switches, level switches,
motor starter contacts, relay contacts,
thumbwheel switches
Input modules sense ON/
OFF or OPENED/
CLOSED signals. Discrete
signals can be either AC or
DC.
Discrete output
module and block
I/O module
Alarms, control relays, fans, lights, horns,
valves, motor starters, solenoids
Output module signals
interface with ON/OFF or
OPENED/CLOSED
devices. Discrete signals
can be either AC or DC.
Analog input
module
Thermocouple signals, RTD signals, tem-
perature transducers, pressure transduc-
ers, load cell transducers, humidity
transducers, flow transducers, potentiom-
eters.
Convert continuous ana-
log signals into input val-
ues for ADAM-5000/ECAT
Analog output
module
Analog valves, actuators, chart record-
ers, electric motor drives, analog meters
Interpret ADAM-5000/
ECAT output to analog sig-
nals (generally through
transducers) for field
devices.
25
