28
CONFIGURING THE SECURITY SETTINGS
Almost all 802.11 networks use some sort of security to protect the network from unauthorized use. There
are many types of security options available. The following section will cover how to configure the device for
the most popular options. If your security configuration is not covered, further details can be found in the
Airborne Enterprise CLI Reference Manual.
CONFIGURING FOR WEP SECURITY
Although an old protocol WEP is still used by many networks, the Airborne device supports many variations
of WEP. However, only the most popular ones are covered in the following table. If the basic 64 or 128 bit
WEP configuration does not work, please refer to the Airborne Enterprise CLI Reference Manual for the
other available options.
Table 18 - Configuring for WEP Security
Step
Description
Navigation Bar
Select Configuration
You will see a group of fields under the banner of WLAN
Parameters.
Feature Link
Select WLAN Security
Settings
The wireless interface must be configured before configuring
the security for the network.
A page showing the range of security options and fields is
displayed.
Select Wireless LAN
Security
Select WEP64 or WEP128 from the drop down list.
The options identify the length of the key that will be used
with the security protocol.
Select Authentication Type
Select Auto from the drop down list. This field should not
need to be changed. Only modify if you have been specifically
told to by the network administrator.
Select Default WEP Key
Select the key number that matches the selection used by the
AP’s in the wireless network. This must match for
authentication to be successful.
There must be a valid key in the selected key number field.
Select WEP Key 1 - 4
Select the key field that matches the one selected in Default
WEP Key field. Enter the key exactly as it is entered into the
AP.
If WEP64 is selected the key length is 10 digits.
If WEP128 is selected the key length is 26 digits.
More than one key field can be completed.
Press Commit [Button]
Saves changes to the device.
Optional
Press Reload [Button]
Reloads the WLAN Settings page. Select this is you have
further configuration options to change.
Optional
Press Restart [Button]
Restarts the device. After the device as rebooted, it will
attempt to authenticate to the configured network. As long as
the network is in range the wireless interface will connect.
If the network is using DHCP, then an IP address will be
assigned to the WLAN interface and IP connectivity is possible
over the WLAN network.
If the network is using static IP addresses, it will be
necessary to configure the network interface. See the next
step.
Feature Link
Select Network Settings
The wireless interface is now configured. However, if the
WLAN network does not have a DHCP server available to
