19
USING THE WEB INTERFACE
Advantech Device Servers and Wireless Adapters include a web interface that provides access to module
status, parameter modification, certificate and configuration file management. To use the web interface,
follow the steps outlined in section 14.0 to establish the IP address of the module. Once the IP address is
known, open a web browser and enter the IP address of the module in the URL window.
The web interface currently supports Internet Explorer v6.0 thru 9.0, Firefox v3.x+, Opera v9.6+, Chrome
v4.0+ and Safari v5.0.5+.
When the authentication request is returned enter:
Figure 6 - Website Login
Username: dpac
Password: dpac
After successfully authenticating with the module, you will be logged into the web server. If this is the first
time you have accessed the device the Express Setup page will be displayed see section 16.0 for
configuration of the device using this page. If you have previously configured the device the default home
page will be displayed (see Figure 5). From here you can update device settings if required. A quick
overview of the web interface follows.
Figure 7 - Default Home Page
NAVIGATION BAR
Figure 8 - Website Navigation Bar
Table 11 - Navigation Bar Items
Title
Description
Status
Provides status and performance characteristics for the network interfaces
available. Includes connection status, radio and Ethernet statistics.
