INSTRUCTIONS FOR USE ENGLISH
9099980000 - SC500 13
11/2014
revised 07/2017
Brush or pad-holder removal/installation (REV system)
1. Make sure that the REV deck (37) is lifted.
2. Turn off the machine and remove the user key (52).
3. According to the kind of cleaning to be performed, install
the pad (A, Fig. 3) or the brush (C, optional) and note the
following:
• Place the pad (A) under the deck and press it until it is
fastened with the Velcro of the drive disc (B).
• Place the brush (C, optional) under the deck, and then
match the centering pins (D) to the respective holes of
the drive disc (B), and then engage the brush with the
three mounting screws (E).
4. To remove the pad or brush, proceed in the reverse order.
A
B
E
C
D
Figure 3
P100857
Squeegee installation
1. Install the squeegee (A, Fig. 4) and fasten it to the bracket
(C) with the handwheels (B).
2. If necessary, adjust the squeegee with the knob (D) so that
the rear blade (E) and front blade (F) touch the oor as
shown in the gure.
Solution tank lling
CAUTION!
Use only low-foam and non-ammable
detergents, intended for automatic scrubber
applications.
WARNING!
When using oor cleaning detergents, follow
the instructions on the labels of the detergent
bottles.
To handle oor cleaning detergents, wear
suitable gloves and protections.
NOTE
If the machine is equipped with EcoFlex system pour
clean water in the tank, otherwise pour solution.
1. Ensure that the solution valve (18) is open (18-A).
2. To ll the solution tank (21) use the front ller (22), or open
the cap (24) to access the side ller.
A
E
B
D
F
B
C
Figure 4
P100843
9099980000(C)07-2017.indb 13 14/06/2017 08:24:05
