INSTRUCTION FOR USE ENGLISH
9099602000 - SC450 9
8/12
TECHNICAL DATA
Model SC450
Solution tank capacity 10.5 US gal (40 liters)
Recovery tank capacity 11.9 US gal (45 liters)
Machine length 46.4 in (1,180 mm)
Machine width without squeegee 22 in (559 mm)
Machine height 41.7 in (1,060 mm)
Brush diameter 20 in (530 mm)
Squeegee width 30 in (760 mm)
Cleaning width 20 in (530 mm)
Front wheel diameter 10 in (254 mm)
Wheel specic pressure on the oor 710 psi (4.9 N/mm
2
)
Brush/pad pressure on the oor with full tank and lowered squeegee 66 lb (30 kg)
Min/max solution ow 0.10 ÷ 0.42 gpm (0.4 ÷ 1.6 liters/min)
ECO solution ow 0.10 gpm (0.4 liters/min)
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 68 dB(A) ± 3 dB(A)
Machine sound pressure level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 85 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) < 98.4 in/s
2
(< 2.5 m/s
2
)
Maximum gradient when working 2 %
IP protection class X4
Protection class (electric) III
Vacuum system motor power 0.44 hp (330 W)
Vacuum system circuit capacity 0.0107 MPa (1,100 mmH
2
O)
Brush motor power 0.64 hp (480 W)
Brush speed 154 rpm
Total absorbed power 34 A (0.8 kW)
Battery compartment size (width x length x height) 13.7 x 13.7 x 11.8 in (350 x 350 x 300 mm)
Battery voltage 24 V
Standard battery (2) Dry: 12 V 70 Ah C5
Battery charger 100-240 VAC
Standard battery autonomy 2 hours
Weight without batteries and with empty tanks 167 lb (76 kg)
Gross vehicle weight (GVW) 419 lb (190 kg)
Shipping weight 227 lb (103 kg)
Machine material composition and recyclability
Type Recyclable
percentage
SC450
Aluminium 100 % 8 %
Electric motors - various 29 % 18 %
Ferrous materials 100 % 19 %
Wiring harnesses 80 % 1 %
Liquids 100 % 0 %
Plastic - non-recyclable material 0 % 1 %
Plastic - recyclable material 100 % 9 %
Polyethylene 92 % 42 %
Rubber 20 % 2 %
9099602000(2)04-2014.indb 9 08/04/2014 12:41:39
