6 - FORM NO. 70139A - Pacesetter 13, 17, 20, 17HD, 20HD, 20TS, 20SD
EN
ENGLISH
TROUBLESHOOTING
SWIRLS ON THE FLOOR AFTER SCRUBBING
• Floor not clean.
• Incorrect solution.
• Area not properly swept - debris in pad or brush.
• Improper pad or brush for the job.
• Moving the machine too fast.
SWIRLS ON THE FLOOR AFTER DRY BUFFING
• Moving the machine too fast.
• Floor finish too soft.
• Area not properly swept - debris in pad or brush.
• Improper pad or brush for the job.
CIRCLES ON THE FLOOR
• Machine standing still while the brush or pad is running.
FLOOR FINISH REMOVED
• Improper pad... too aggressive.
• Solution too strong.
MACHINE WOBBLES DURING OPERATION
• Defective pad... one side is more dense than the other.
• Machine left sitting on brush or pad for extended period of time causing bristles or pad to “take a set”.
• Pad not “seated” properly into pad holder bristles.
• Warped block on brush or padholder - replace.
MACHINE DOES NOT RUN
• Check plug for proper connection - on machine and at wall outlet.
• Check building circuit breaker.
• Call for service.
TECHNICAL SPECIFICATIONS (as installed and tested on the unit)
Model Pacesetter™ 13 Pacesetter™ 17 Pacesetter™ 20
Model Number 01282A 01290A 01370A
Motor 1 hp 1 hp 1 hp
Transmission Two-Planetary Two-Planetary Two-Planetary
Clutch Plate NP-92 NP-92 NP-92
Pad/Brush Speed 175 rpm 175 rpm 175 rpm
Pad/Brush Size 13” (33 cm) 17” (43 cm) 20” (51 cm)
Wheels 5” (13 cm) 5” (13 cm) 5” (13 cm)
Cord Length 50’ (15 m) 50’ (15 m) 50’ (15 m)
Height w/Handle 46” (117 cm) 46” (117 cm) 46” (117 cm)
Weight (w/cord) 81 lbs. (36.8 kg) 83 lbs (37.7 kg) 87 lbs (39.5 kg)
Construction:
Handle Tube Tubular Steel Tubular Steel Tubular Steel
Base Die-Cast Aluminum Die-Cast Aluminum Die-Cast Aluminum
Model Pacesetter™ 17HD Pacesetter™ 20HD Pacesetter™ 20TS Pacesetter™ 20SD
Model Number 01330A 01410A 01440A 01460A
Motor 1.5 hp 1.5 hp 0.9/1.5 hp 1.75 hp
Transmission Triple-Planetary Triple-Planetary Triple-Planetary Triple-Planetary
Clutch Plate NP-92 NP-92 NP-92 NP-92
Pad/Brush Speed 175 rpm 175 rpm 180/320 rpm 175 rpm
Pad/Brush Size 17” (43 cm) 20” (51 cm) 20” (51 cm) 20” (51 cm)
Wheels 5” (13 cm) 5” (13 cm) 5” (13 cm) 5” (13 cm)
Cord Length 50’ (15 m) 50’ (15 m) 50’ (15 m) 50’ (15 m)
Height w/Handle 46” (117 cm) 46” (117 cm) 46” (117 cm) 46” (117 cm)
Weight (w/cord) 91 lbs (41.1 kg) 95 lbs (43.2 kg) 81 lbs (36.8 kg) 102 lbs (46 kg)
Construction:
Handle Tube Tubular Steel Tubular Steel Tubular Steel Tubular Steel
Base Die-Cast Aluminum Die-Cast Aluminum Die-Cast Aluminum Die-Cast Aluminum
