43
FORM NO. 56091111
BU800 20B, 20BT
9/2013
Item Ref. No. Qty Description
1 962823 5 Screw, 1/4-20X 1/2 P.H.
2 41801A 2 Contactor, Main 36V
3 61909A 1 Cover, Front Electric Plate
4 79985A 1 Label, Battery Conn.
5 79984A 1 Label, Connection Dia.
7 42401A 1 Diode, Asm. Contactor
8 41022A 1 Diode, Avalanche Asm.
9 41042A 1 Controller, i-Drive 36V Traverse
10 56381710 1 Plate, Electrical Weldment
11 80380A 2 Screw, 8-32 x 1 1/4” P.H.
12 41448B 1 Breaker, 30A Circuit
14 980614 4 Washer, 1/4” Starlock Ext.
15 920208 4 Nut, 1/4-20 Hex
16 87200A 3 Washer, Lock #8
17 920108 3 Nut, 8-32
18 30778A 1 Cover, Lower
19 980651 2 Washer, 5/16 Flat
20 56002873 3 Nut, 10-32 Hex
22 52548A 3 Tab, 1/4” Screw
23 962957 3 Screw, 10-16 x 1/2 Self Tap
24 56383487 1 Switch-Tilt
25 54770A 2 Fastener, Ratchet
26 98470A 3 Screw, 10-32 x .500
27 980652 2 Washer, 5/16 Lock
28 85811A 2 Screw, 5/16-18 x 3/4” Hex Hd.
29 41007A 1 Relay, Traverse Power
30 962027 1 Screw, 8-32 x 1/2 P.H.
31 38740A 1 Strap, Retention (Dust Bags)
32 84237A 6 Screw, 10-32 x .50 P.H.
33 40740A 1 Cord, Charger NEMA
34 61598A 1 Bracket, Cord Wrap
35 85395A 2 Screw, 1/4-20 x 1/2” P.H.
36 38739A 1 Cover, Harness
37 56383543 2 Decal-BU800
38 56383244 3 Trim Lock 4-Inch
39 56393722 1 Circuit Breaker 70A
40 699202 9 Wire Tie
41 56478246 4 Cable Tie
[ ] 41041A 1 Harness, Power 20” Traverse
[ ] 41038A 1 Harness, Logic 20” Traverse
[ ] = Not Shown
1/2017
BODY ASSY - BU800 20BT
