FORM NO. 56091111
BU800 20B, 20BT
9/2013
Item Ref. No. Qty Description
1 1 Chassis Weldment (not available for sale)
2 56002098 2 Wsh, Flt Sae 1/4
3 56109766 2 Screw Button Head 1/4-20 X .63
4 962950 2 Screw 1/4-20X3 PN ST PH
5 56003859 2 Wsh-Serrated Ext Ss M10
6 56383251 4 Mount Vibration Damping
7 56383203 2 Seat Soft Spring
8 56383204 1 Gasket Charger
9 56383205 4 Spacer Steel
10 56383212 1 Head Lift Weldment 20/24
11 56383250 4 Scr Button Soc 3/8-16 X 2.00
13 87060A 1 Bushing Insulating
15 920148 1 Nut, 3/8-16 Hex Jam
17 920342 6 Nut Esna 3/8-16
19 962620 2 Screw, 5/16-24 X 3/4” Hex Hd.
20 980205 3 Washer, .31 I.D. X 1.06 O.D.
21 980645 4 Washer, 3/8” S.A.E. Flat
22 980651 8 Washer, 5/16 Flat
23 980652 10 Washer, 5/16 Lock
24 980657 2 Washer, Lock 1/4
25 56381751 1 Plate Spring Base
26 56381777 2 Spring Compression 20
27 56382846 1 Screw Head Pressure Adj
28 41036A 1 Charger, Battery 36vdc/21a
29 56383396 2 Caster Swivel 3.5 Sealed
30 54691A 2 Wheel, 8”
31 54768A 1 Clamp P 5/16 Steel
32 57423A 2 Retaining Ring External Sh .75 Heavy
33 61917A 1 Weldment, Non-Traverse Axle
34 69639A 1 Strap, Static
35 56002491 1 Nut Hex Nyl Loc Ss 1/4-20
36 81220A 2 Nut, Serrated Flange
37 85700A 2 Screw, 1/4-20 X 1 H.H.C.S.
38 85811A 8 Screw, 5/16-18 X 3/4 Hex Hd
39 87616A 2 Washer, FLT, 1.00x.75x.06 Nylon
40 56383253 4 Washer Snubbing
FRAME ASSY - BU800 20B
