07-05
FORM NO. - 71279A - ADVOLUTION 20, 20XP - 23
revised 11/11
ADVOLUTION 20 ASSY
Item Ref. No. Qty Description
1# 56109768 1 Spring Gas TSBUS2011-0021
2# 56109743 1 Release Pedal Weldt TSBUS2011-0021
3
# 56109770 1 Mainframe Advance NDC TSBUS2011-0021 NOTE 1
4 56201018 4 Wheel 5.00 X 1.50
5 613920 1 Handle T-Knob
6 980413 1 Washer Retainer
7 980673 8 Washer Flat 1/2 X 7/8 X 3/64
8 11187A 1 Handle, Asm
9# 29916A 1 Mount Motor TSBUS2011-0021
10 30740A 1 Cover Motor
11 40935A 1 Motor 1.5hp 120/60 1500 Rpm
41029A 1 Motor, 1.1 kW 230V 1500 RPM
12 53793A 2 Pin Coiled 1/2 X 2.25
13 53836A 1 Spring Compression
14 54196A 2 Spring Extension
15
# 56925A 1 Pad Driver TSBUS2009-1034
[ ] 57369A 1 Retainer, Pad
[ ] 57370A 1 Base, Retainer
16 61867A 1 Tube Mount Weldment
17 61868A 1 Pull-Pin Stem
18 61869A 1 Axle Rear
19 61871A 2 Axle Front
20 61872A 1 Axle Folding
21 61874A 1 Axle .50 X 7.60
22 71333A 1 Label Cover Motor 20
23 80284A 4 SCREW 10-32 UNF X .75 H.R.C.S.
24 80292A 10 Screw .25-20 X 1.00 Bhhr Sems
25 80295A 5 Washer Bowed
26
# 80297A 4 Screw 1/4-20 X 1.75 Bh Zp Sems TSBUS2011-0021
27 80378A 1 Ring Retaining External 0.750”
28
# 56382561 4 Spacer TSBUS2011-0021
29
# 40257A 1 Adapter 5-15p To CEI 23-16/VII
MOTOR SERVICE PARTS
[ ] 912287 1 Rectifi er (120V)
[ ] 46105A 1 Rectifi er (240V)
[ ] 902550 1 Bearing 6203 (Upper)
[ ] 902547 1 Bearing 6205 (Lower)
[ ] 980076 1 Wave Washer
[ ] 51435A 1 Brush Board Assembly (120V)
[ ] 448396 4 Spring (part of 51435A)
[ ] 51405A 4 Brush, Carbon (part of 51435A)
[ ] 59606A 1 Varistor (part of 51435A)
[ ] 55647A 1 Yellow Lead (part of 51435A)
[ ] 55648A 1 Red Lead (part of 51435A)
[ ] 40411A 1 Brush Board Assembly (240V)
[ ] 448396 4 Spring (part of 40411A)
[ ] 40819A 4 Brush, Carbon (part of 40411A)
[ ] 59607A 1 Varistor (part of 40411A)
[ ] 55647A 1 Yellow Lead (part of 40411A)
[ ] 55648A 1 Red Lead (part of 40411A)
# = Revised or new since last update
NOTE 1: If you need to replace Mainframe 30738A please order Mainframe Kit 56109779
