Je bekijkt pagina 6 van 16
ADJ Products, LLC www.adj.com - WiFly WLC16 Page 11
WiFly WLC16 Operation
The 512CH DMX Controller allows you to program 512 DMX channels
each. 30 Banks of 16 Programmable scenes, 6 chases of 480 scenes
using 16 channel sliders and other buttons.With the SD card slot,you
can insert SD-card to record whole data of controller or edit SD-card
data with computer to run on the controller.
Display Information -
When power is applied to the controller, the LCD will display ”WiFly
WLC16 V1.1”. The LCD Display contains a maximum of 2 lines with
16 characters each. Below are the denitions of what you will see
displayed.
Scene=01 Scene 1 is activated
Bank=01 - Bank 1 is activated
Chase=01 - Chase 1 is activated
CH01=[255] - Channel 1 DMX Value (255)
SPEED Time:[05:30.0] - The current speed is 5 minute 30 seconds
FADE Time:[15.0] - The fade time is 15 seconds
WIFI Address[10] - The wiy radio channel is 10
Step020 - Step 20 is activated or the chase contains 20
Steps
SET UP
Unit Setup
The unit is preset with 32 channels per xture. In order to assign your
xtures to the xture buttons located on the left side of the unit, you
will need to space your xtures 32 DMX channels apart.
Enabling Program Mode -
1) Press and hold down the RECORD button until the LCD displays
”Password:”
2) Press the Scene buttons 1, 2, 3, and 4.
3) If an incorrect password is entered, the LCD will display “Incorrect
pass” on the top line, and “Add to try again” on the bottom line.
4) To re-enter a password press the ADD button and the LCD display
will show “Password” again. Use the Scene buttons to enter your
correct password.
NOTE: The rst time you turn on your unit, the default setting of the
ADJ Products, LLC www.adj.com - WiFly WLC16 Page 10
WiFly WLC16 WiFly Set Up
There are two ways that the controller can run DMX; connected via
3-pin DMX data cable or using the WiFly DMX signal to eliminate data
cables.
NOTE: To set up properly follow the set up instructions associated
with your WiFly xture or WiFly TransCeiver.
1. When using 3-pin DMX data cables, the WiFly DMX switch (4)
must be in the OFF position.
2. When using the WiFly DMX signal, the WiFly DMX switch must be
in the ON position. The antenna must be extended and upright.
The antenna must be in either a up or down position and must
match position of the other antennas. All antennas up or all anten-
nas down.
3. Set the WiFly channel, the WiFly channel must match the set chan-
nel of the xtures that you are controlling. If the channels are not
the same, you will not be able to control the xtures. The WiFly
channel can be set from 0-14. If the WiFly controller is transmitting
a WiFly signal, the WiFly indicator will glow red.
CAUTION: This unit like any wireless device is highly susceptible
to static electricity. Static electricity can severly damage the unit.
Before touching the antenna, please ground/discharge yourself.
