ADJ Products, LLC - www.adj.com - WiFly EXR QA12Bar IP User Manual Page 13
WiFly EXR QA12Bar IP Operating Instructions
Default Running Mode (Reset):
This is a default running mode. When this mode is activated all modes
will return to their default settings and Auto Run will be activated.
1. Plug the fixture in and press the MODE until “OTHER” is dis-
played.
2. Press the SET UP button until “OTHER RESET is displayed. Press
the UP and DOWN buttons simultaneously. The unit will now reset
to the default settings. If the reset worked correctly, the unit will
reset into Auto Run mode.
ADJ RFC:
This function is used to activate and deactivate the ADJ RFC (Remote
Control). When this function is activated you can control the fixture
using the ADJ RFC. Please see the next page for ADJ RFC controls
and functions.
1. Plug the fixture in and press the MODE button until “OTHER” is
displayed. Press the SET UP button until RF:XXX” is displayed.
“XXX” represents either ON or OFF. Use the UP or DOWN buttons
to turn the remote function either ON or OFF.
WiFLY Address Setting/WiFly On/Off:
This function is used to set the WiFly address and activate/deactivate
the WiFly function. The address must match the address that is set to
your WiFly TransCeiver or WiFly controller.
1. Plug the fixture in and press the MODE button until “WIFI SET
ADDR: XX” is displayed. “XX” represents a number between
00-14.
2. Use the UP or DOWN buttons to find and set your desired WiFly
address. The address must match the address that is set to your
WiFly TransCeiver or WiFly controller.
3. After you have found and set your WiFly address, press the SET
UP button to activate WiFly. “WIFI SET STAT: XXX” will now be
displayed. Use the UP or DOWN button to set the display to “On”
to activate WiFly. To deactivate WiFly set the display to “Off”.
DMX State:
This mode can be used as a precaution mode, that in case the DMX
signal is lost, the operating mode chosen in the setup is the running
mode the xture will go into when the DMX signal is lost. You can also
ADJ Products, LLC - www.adj.com - WiFly EXR QA12Bar IP User Manual Page 12
set this as the operating mode you would like the unit to return to when
power is applied.
1. Plug the fixture in and press the MODE button until “DMX MODE
ADDR:XXX” is displayed.
2. Press the SET UP button until “DMX MODE NO: XXXX” is dis-
played. “XXXX” represents the current DMX state that is displayed.
3. Use the UP or DOWN buttons to select the operating mode you
would like the unit to start up in when power is applied or the
DMX signal is lost.
• AUTO - If the DMX signal is lost or power is applied, the unit will auto-
matically into Auto Run.
• BLACK - If the DMX signal is lost or power is applied, the unit will
automatically go into stand by mode.
• HOLD - If the DMX signal is lost the xture will stay in the last DMX set
up. If power is applied and this mode is set, the unit will automatically
go into the last DMX set up.
Dimmer Curve:
This is used to set the dimming curve used with DMX mode. See
page 26 for the different dimming curve chart.
1. Plug the fixture in and press the MODE button until “DMX MODE
ADDR:XXX” is displayed.
2. Press the SET UP button until “DELAY:X” is displayed. “X” repre-
sents the displayed dimmer curve (0-4).
• 0 - Standard
• 1 - Stage
• 2 - TV
• 3 - Architectural
• 4 - Theatre
3. Press the UP or DOWN buttons to scroll through and select your
desired dimming curve.
WiFly EXR QA12Bar IP Operating Instructions
