ADJ Products, LLC - www.adj.com - WiFly Bar RGBA User Manual Page 11
WiFly Bar RGBA Operating Instructions
displayed. Then press the SET UP button to adjust intensity of the
individual colors.
2. When “r.XXX” is displayed you are in Red dimming mode. Press
the UP and DOWN buttons to adjust intensity.
3. When “G.XXX” is displayed you are in Green dimming mode.
Press the UP and DOWN buttons to adjust intensity.
4. When “b.XXX” is displayed you are in Blue dimming mode. Press
the UP and DOWN buttons to adjust intensity.
5. When “A.XXX” is displayed you are in Amber dimming mode.
Press the UP and DOWN buttons to adjust intensity.
6. After you have adjusted the RGBA colors to make your desired
color you can then activate strobing by pressing the SET UP but-
ton to enter the Flash (strobe) mode.
7. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
Built-In Program Mode:
1. Plug the fixture in and press the MODE button until “Pr.XX” is dis-
played. “XX” represents a number from 1-22. Use the UP or DOWN
buttons to scroll through the 22 programs. Programs 21 and 22
have adjustable colors. Once you have found your desired program
press the SET UP button.
2. Pressing the SET UP button will display “SP.XX”. When this is dis-
played you can adjust the running speed of your desired program.
Use the UP or DOWN button to adjust the speed between “SP.01”
(slowest) and “SP.99” (fastest). Once you have set your desired run-
ning speed, you can press the SET UP button to to enter the Fade
adjustment mode.
2. Pressing the SET UP button will display “Fd.XX”. When this is dis-
played you can adjust the fade speed of your desired program.
Use the UP or DOWN button to adjust the speed between “Fd.01”
(fastest) and “Fd.99” (slowest) or “Fd.00” (Off). Once you have set
your desired fade speed, you can press the SET UP button to to
enter the Flash (Strobe) mode.
3. After pressing SET UP, “FS.XX” will be displayed, this is Flash mode.
The Flash can be adjusted between “FS.00” (flash off) to “FS.15”
(fastest flash).
• PROGRAMS 21 & 22 - If you have chosen programs 21 or 22, after
the Flash mode, press the SET UP button. “C1.XX” will be displayed.
WiFly Bar RGBA Operating Instructions
Operating Power:
There are two ways to supply power to this unit; battery power or AC
power.
• AC Power - To run the unit using AC power, plug the unit into a power
source, and put the Load Switch into the ON position. When using AC
power make sure the Battery Switch is in the OFF position.
• Battery Power - To run the unit using Battery power, put the Load and
Battery Switches in the ON position.
LED Display On/Off: To make the display stay ON all of the time
press the MODE and UP buttons at the same time. To make the dis-
play turn OFF after 20 seconds, press the MODE and DOWN buttons
at the same time.
Operating Modes:
The WiFly Bar RGBA has six operating modes:
• Static Color Mode - There are 15 colors to choose from.
• RGBA Mode - Choose one of the four colors to remain static or
adjust the intensity of each color to make your desired color.
• Built-In Program - There are 22 built-in programs to choose from.
• Auto Run Mode - A auto program will run with adjustable fade
speed.
• Sound-Active mode - The unit will react to sound, chasing through
the built in programs.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller.
Static Color Mode:
1. Plug the fixture in and press the MODE button until “C0.XX” is
displayed.
2. There are 15 colors to choose from. Select your desired color by
pressing the UP and DOWN buttons. After you have selected
your desired color you can activate strobing by pressing the SET
UP button to enter the Flash (strobe) mode.
3. “FS.XX” will now be displayed, this is Flash mode. The Flash can
be adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
RGBA Dimmer Mode:
1. Plug the fixture in and press the MODE button until “r.g.b.A” is
ADJ Products, LLC - www.adj.com - WiFly Bar RGBA User Manual Page 10
