American DJ® - www.americandj.com - Vizi Spot LED PRO - Instruction Manual - Page 16American DJ® - www.americandj.com - Vizi Spot LED PRO - Instruction Manual - Page 15

Vizi Spot LED PRO System Menu

RPAN (REVERSE PAN) MENU -

ON/OFF - When “On” is chosen it will reverse the pan.

RTILT (REVERSE TILT) MENU -

ON/OFF - When “On” is chosen it will reverse the tilt.

FINE MENU -

ON/OFF - Switch between 8bit (coarse) and 16bit (ne) pan & tilt

movement. This also switches the DMX channel mode between

10 channel (8 bit) and 12 channel (16 bit) DMX mode.

DEGR MENU -

540/630 - Switch the degree of the Pan between 630 and 540.

MIC MENU -

M-01-M-70 - With this function you can make the internal mic

more or less sensitive to sound.

DISPLAY MENU -

VALU (DMX-512 Value) - Display the DMX-512 value of each

channel.

D ON - Display will turn o in 2 minutes.

FLIP - “Flips” the digital display 180º.

LOCK - When activated the buttons will lock automatically. See

page 25 for more information.

SPEC MENU -

RDMX - Lets you adjust the DMX address via external controller.

SPOT - This provides a spot beam for better lamp optimization.

DFSE (Default Settings) - Resets the unit to the default settings.

FEED - Pan/Tilt feedback (error correction) on/o.

FANS - Select the fan running mode.

HIBE - This feature will automatically shut down the lamp and

stepping motors. Please see pages 28-29.

Vizi Spot LED PRO System Menu

ADDRESS MENU -

AOO1 - A511 (Value) - This is where you set the DMX address of

the unit.

TEST MENU -

T-01 - T-XX (Test) - Tests the functions of each channel.

Note: Some channels cannot be tested.

PLAY MENU -

RUN - Runs the unit as a “master” or in a stand alone mode. The

unit will run a internal program mode.

AUDI (Audio) - Runs the unit as a “master” or in a stand alone,

sound active mode.

AUTO - This is a precaution mode in case the DMX signal is lost.

There are four settings to choose from:

• “Hold” - This is the default setting, which in case the signal is

lost the xute will “hold” at the last setting.

• “Close” - The xture will return to its “home” standing.

• “Auto” - The xture will go into Auto mode and run a pre-pro-

grammed show.

• “Audi” - The xture will go into Sound Active mode.

RESE (RESET) MENU -

ALL - Resets all the motors in the unit.

SCAN - Resets the motors that control pan/tilt.

COLR (Color) - Resets the color motors.

GOBO - Resets the gobo motors.

OTHR - Resets all other motors.

TIME MENU -

LIFE - Displays the xtures total running time.

CLMP - Clears the xture running time.
