Vizi Scan LED PRO Controls and Functions
1. Mirror - This is a highly reective surface mirror specically designed
to optimize and enhance beam output. Never use glass cleaners that
contain ammonia to clean the surface of the mirror (such as Windex).
2. Lens Assembly - This high quality lens is a fully focusing. Focus
the lens by manually turning the lens in a clockwise or counter-clock-
wise direction until the desired effect is achieved.
3. Digital Display - This display shows the menu and operating func-
tions that you can choose from.
4. Mode/Esc Button - This button is used to enter the main menu and
submenus. It is also used to exit menus.
5. Up Button - This button is used to scroll forward when navigating
through the system menu.
6. Down Button - This button is used to scroll backwards when navi-
gating through the system menu.
7. Enter Button - This button is used to select and conrm a function
in the system menu.
8. Microphone - This microphone receives external low frequencies
to trigger the unit in Sound-Active mode. This microphone is designed
to receive low frequency sounds only, tapping on the microphone and
high pitch sounds may not trigger the unit.
9. Control Board
10. XLR DMX Input Jack - This jack is used to receive an incoming
DMX signal or Master/Slave signal.
11. XLR Output Jack - This jack is used to transmit the incoming
DMX signal to another DMX xture, or transmit a Master/Slave signal
to the next Vizi Scan LED PRO in the chain. For best results in DMX or
Master/Slave mode terminate this jack if it is the last unit in the chain.
See “Terminator” on page 13.
12. Power Cord - This cord used to supply power to the unit. Never
use this unit if the cord is broken or frayed. Never use this xture if the
ground prong has been removed or broken off. The ground prong is
designed to reduce the risk of re or electrical shock in the event the
unit suffers from an internal short.
American DJ® - www.americandj.com - Vizi Scan LED PRO Instruction Manual Page 9
American DJ® - www.americandj.com - Vizi Scan LED PRO Instruction Manual Page 10
Vizi Scan LED PRO Controls and Functions
