Vizi Q Wash7 System Menu
The main menu is accessed by pressing the MODE button. Browse through the menu
by using the UP, DOWN, RIGHT, & LEFT buttons. Press the ENTER button to access
the desired menu. You can scroll through the sub-menus using the UP, DOWN, RIGHT,
& LEFT buttons. To conrm every selection press the ENTER button. You can exit every
menu and sub-menu by pressing the MODE button. The unit will automatically exit the
menus if no buttons are pressed after 10 seconds. These next pages will explain each
function in the menu layout located on the previous page.
RECEIVE -
Set Address - With this function, you can adjust the desired DMX-address via the Control
Board.
1. Access the main menu, and press the UP or DOWN buttons so that “Receive” is
highlighted, then press ENTER.
2. “Set Address” will now be displayed, press ENTER. The current DMX address will
now be displayed.
3. Use the UP or DOWN buttons to adjust the DMX address.
4. Press ENTER to conrm or press MODE to return to the main menu.
USER MODE
User Mode - This mode will let you select your desired DMX Channel mode.
1. Press the MODE button to access the main menu. Press the UP or DOWN buttons so
that “User Mode” is highlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons until “User Mode” is displayed, press ENTER.
3. Use the LEFT or RIGHT buttons to scroll through the 3 DMX Channel Modes.
Standard Mode - This is 19 Channel Mode.
Basic Mode - This is 17 Channel Mode.
Extended Mode - This is 23 Channel Mode.
User Mode A B C - These are customizable DMX modes. Select either of these modes
and set the amount of DMX Channels and what each channel does.
4. Press the MODE button once to return to the “User Mode Set” menu.
ADJ Products, LLC — www.adj.com — Vizi Q Wash7 — Page 22
