American DJ® - www.americandj.com - Vizi LED Spot - Instruction Manual - Page 37 American DJ® - www.americandj.com - Vizi LED Spot - Instruction Manual - Page 38

Operating Modes: The Vizi LED Spot can operate in three dif-

ferent modes. This next section will detail the differences in the

operating modes.

• Stand alone mode -

The unit will react to sound, or chase through the built-in programs.

• Master/Slave mode -

You can daisy chain up to 16 units together to get a synchronized

light show without the need of an external controller. The units will

react to sound or chase through the built-in programs.

• DMX control mode -

This function will allow you to control each individual fixtures traits

with a standard DMX-512 controller such as the Elation® Show

Designer.

™

Universal DMX Control: This function allows you to use a uni-

versal DMX-512 controller such as the Elation® DMX Operator™ or

Elation® Show Designer™ to control head movement, the color wheel,

gobo wheel, prism, and the shutter (strobe). A DMX controller allows

you to create unique programs tailored to your individual needs.

1. The Vizi LED Spot has a 10 channel DMX mode and 12 channel

DMX mode. To select your desired DMX mode please see page

23 “FINE” menu See pages 40-45 for detailed description of the

DMX traits.

2. To control your fixture in DMX mode, follow the set-up procedures

on pages 10-12 as well as the set-up specifications that are

included with your DMX controller.

3. Use the controller’s faders to control the various DMX fixture traits.

4. This will allow you to create your own programs.

5. Follow the instruction on page 18 to set the DMX address.

6. For longer cable runs (more than a 100 feet) use a terminator on

the last fixture.

7. For help operating in DMX mode consult the manual included

with your DMX controller.

Stand-Alone (Sound Active or Auto Program): This mode allows

a single unit to run to the beat of the music or run through a built-in

program.

1. Access the main menu.

Vizi LED Spot Operation

02Er – TILT movement error:

If the head is not located in the default tilt position after start-

up or after a reset command. This message will appear after a

xture reset, if the tilt magnetic-indexing circuit malfunctions

(sensor failed or magnet is missing) or there is a stepper motor

failure (defective motor or a defective motor IC drive on the

main PCB).

Vizi LED Spot Error Codes
