ADJ Products, LLC - www.adj.com - Vizi Hybrid 16RX Instruction Manual Page 10 ADJ Products, LLC - www.adj.com - Vizi Hybrid 16RX Instruction Manual Page 11
Vizi Hybrid 16RX CAD Drawing
Vizi Hybrid 16RX Base Layout
Front view Rear view
6. Power Cable: To connect to the mains supply
7. Power Switch: Turns On/O the power.
1. LED:
POWER On Power on
DMX On DMX input present
2. Display: To show the various menus and the selected function.
3. Button:
MENU To enter into move backward or leave the menu
UP To go backward to move up in the menu
DOWN To go to move down in the menu
ENTER To perform the desired functions
4. DMX input/output: For DMX 512 operation, use 3/5-pin XLR plug cable to link the units together
5. Fuse (T 10A): Protect the unit from damage of over current.
