ADJ Products, LLC ! ww.adj.com ! VIZI CMY 16RX User Instructions Page 40
Model
VIZI CMY 16RX
Voltage:
100~240V, 50/60Hz
Power Consumption:
520 W
Power Draw @ 120V:
5.2 amps
Power Draw @ 220V:
2.4 amps
Lamp:
Philips Platinum 16R MSD
Color Temperature:
8,000K
Life Expectancy:
1,500 Hours
Beam Angle:
10 Degrees (Beam Mode)
5 – 22 Degrees (Spot Mode)
22 – 63 Degrees (Wash Mode)
Zoom Range:
6 – 22 Degrees
Shutter:
Motorized
Zoom:
Motorized
Focus:
Motorized
Prism:
5 Facet Linear
16 Facet Circular w/ Macros, Rotating & Layering
Frost:
Frost Filter + Wash Effect
Strobe/Shutter Rate:
0.3 – 7HZ
Colors:
Full CMY Color Mixing
Additional color wheel with 9 colors + white
Gobos:
Wheel 1: 9 static gobos and 6 static apertures
Wheel 2: 9 rotating, replaceable gobos
Glass Gobo Size:
15.8 mm (12mm viewable)
Fuse:
10A
Control:
DMX, Stand Alone, RDM (Remote Device
Management)
DMX:
3/5pin with 22/24 Channels
IP Rating:
IP20
Warranty:
1 Year (365 Days)
Dimensions (LxWxH):
25” x 16.25” x 13” (639x413x326mm)
Weight:
52lbs / 23.2 kg
Please Note: Specifications and improvements in the design of this unit and this manual are
subject to change without any prior written notice.
VIZI CMY 16RX
Specifications
