ADJ Products, LLC ! ww.adj.com ! VIZI CMY 16RX User Instructions Page 38
The glass gobo’s are the only gobo’s that are interchangeable in this unit. Remember
when changing these gobo’s they are glass. Please do this process gently so you do
not break the gobo.
Caution! Never open the unit when in use. Always disconnect the main power before
attempting to change the gobos.
!
1. To change a gobo, rotate the moving head so the instructions on the rear of
unit are upside down.
2. Unscrew the 4 screws that secure the shell to the unit. The shell is attached
to the unit by a safety wire. Gently lift the shell off of the unit.
3. When you remove the shell, you will be able to access the gobo wheel. Turn the
wheel with your hand until you come across the gobo you would like to change.
4. You have to remove the individual gobo frames. Gently push the gobo frame
(Not the wheel) away from the gobo wheel; you do not have to the push gobo
frame too far. While you are pushing the gobo frame away from the wheel, pull
the gobo frame up and out.
5. Once the gobo frame has been removed, gently remove the fixture ring. The
fixture ring should easily come out of the frame. After the fixture ring is
removed, remove the gobo.
6. Change the gobo and replace the fixture ring. When inserting the gobo frame back
into the unit, the bottom of the gobo frame must slide underneath the metal
placeholder located at the bottom of the gobo frame slot in the wheel.
7. Reassemble the unit.
VIZI CMY 16RX
Changing the Glass Gobo
