SPECIFICATIONS
Primary Light Source: 4 pcs high-power 150W COB
amber LED
• CCT: 2000K
• Lumens: > 27,000
• Lux: 647 @ 5 meters
• CRI: 70
• Field Angle: 160°
Background Light Source: 120 pcs SMD 5050
RGBL LEDs (0.8W each)
• Configured into 20 pixel groups (6 LEDs per
group)
Dimmer: 0-100% linear dimming system
Special Effects:
• Powerful strobe, 0.5 to 33Hz
• Unique retro RGBL background effect
• Silent operation with low noise
Additional Features:
• Aria X2 Management System
• Flicker-free
• OLED display with a 4-button touch menu
• Capable of interlocking multiple units together
Control Modes:
• Primary/Secondary synchronization
• Stand-alone mode
• DMX512 control mode
• 10 DMX Channel Modes (5/6/8/14/17/18/84/
88/90/97 channels)
• DMX, RDM, sACN and Art-NET protocol support
Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any
prior written notice.
Connections:
• IP20 indoor 5-pin DMX Input and Thru
• IP20 indoor RJ45 Ethernet
• IP65 outdoor power locking Input and Thru
Protection Rating:
• IP20 (for indoor use only)
Dimensions & Weight:
• Dimensions (LxWxH): 35.7” x 11.5” x 10.1” / 908 x
292 x 257mm
• Weight: 41.89lbs. (19kg)
Power:
• Input: AC100-230V/50Hz-60Hz
• Power Consumption: 780W @120V, 750W @
230V
• Power Link: 1 piece @120V or 2 pieces @ 230V
Optional Accessories:
• VFB1 (Floor Base for vertical stand)
• VFB1-VBA (Adapter to adapt Vintage Bar to VFB1
Floor Base. One adapter is required per floor
base)
