ADJ Products, LLC - www.adj.com - Starship User Manual Page 12
Starship DMX Addressing
DMX ADDRESSING
All fixtures should be given a DMX starting address when using a DMX controller, so the correct fixture
responds to the correct control signal. This digital starting address is the channel number from which
the fixture starts to “listen” to the digital control signal sent out from the DMX controller. The assignment of
this starting DMX address is achieved by setting the correct DMX address on the digital control display
on the fixture.
You can set the same starting address for all fixtures or a group of fixtures, or set different addresses
for each individual fixture. Setting all fixtures to the same DMX address will cause all fixtures to react
in the same way, in other words, changing the settings of one channel will affect all the fixtures
simultaneously.
If you set each fixture to a different DMX address, each unit will start to “listen” to the channel number
you have set, based on the quantity of DMX channels of each fixture. That means changing the settings of
one channel will only affect the selected fixture.
In the case of the Starship, when in 22 Channel you should set the starting DMX address of the first unit
to 1, the second unit to 23 (22 + 1), the third unit to 45 (23 + 22), and so on. (See the chart below for more
details.)
ChannelMode
Unit 1
Address
Unit2
Address
Unit 3
Address
Unit 4
Address
22 Channels 1 23 45 67
120 Channels 1 121 241 361
