American DJ® - www.americandj.com - Quad Scan LED Instruction Manual Page 3American DJ® - www.americandj.com - Quad Scan LED Instruction Manual Page 2

• DMX-512 Protocol Compatible (1, 5, or 28 DMX Channels)

• X/Y Mirror Control

• 3 Operating Modes - Sound Active, Show Mode, and DMX Control

• Internal Microphone

• Digital Display for Address and Function Setting

• UC3 Controller (Not Included)

• Power Cord Daisy Chaining (See page 15)

Quad Scan LED Features

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures

warranty. In the unlikely event your unit may require service please

contact American DJ®.

American DJ® will not accept any liability for any resulting damages

caused by the non-observance of this manual or any unauthorized

modication to this unit.

Quad Scan LED Handling Precautions

Quad Scan LED Warranty Registration

The Quad Scan LED carries a 2 year (730 days) limited warranty.

Please fill out the enclosed warranty card to validate your purchase

and warranty. You may also register your product online at www.

americandj.com. All returned service items whether under warranty or

not, must be freight pre-paid and accompany a return authorization

(R.A.) number. If the unit is under warranty you must provide a copy

of your proof of purchase invoice. Please contact American DJ® cus-

tomer support for a R.A. number.

To optimize the performance of this product, please read these

operating instructions carefully to familiarize yourself with the basic

operations of this unit. These instructions contain important safety

information regarding the use and maintenance of this unit. Please

keep this manual with the unit, for future reference.

Quad Scan LED General Instructions

Quad Scan LED General Information

Unpacking: Thank you for purchasing the Quad Scan LED by Ameri-

can DJ®. Every Quad Scan LED has been thoroughly tested and has

been shipped in perfect operating condition. Carefully check the ship-

ping carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all equipment necessary to operate the unit has

arrived intact. In the event damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Please do not return this unit to your dealer without con-

tacting customer support rst.

Introduction: The Quad Scan LED is a DMX intelligent, RGB Tri LED

scanner. The Quad Scan LED can operate as a stand alone fixture or in

a Master/Slave configuration. The Quad Scan LED has three operating

modes; sound active mode, show mode, and DMX control. For best

results use fog or special effects smoke to enhance the beams projec-

tions.

Customer Support: American DJ® provides a toll free customer

support line, to provide help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 8:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Warning! This may cause severe eye damage. Avoid looking directly

into the light source at all times!
