SPECIFICATIONS
Optical:
• 300-Watt, 3000K Warm White C.O.B. LED (Chip On Board)
• • Life expectancy: rated at 50,000 hrs.
• • Manual Zoom: 9°, 15°, 20°, 25°, 30°, 35° and 40°
• • Zoom Ratio: 4.4:1
Photometrics:
• 8878 Lux (Zoomed In to 9° @ 5 meters)
• 1208 Lux (Zoomed Out to 40° @ 5 meters)
• CRI: 97
Connection:
• DMX: 5-pin DMX In/Out
• With Wired Digital Communication Network
• Locking IP20 Power In/Out connections
Control:
• Aria X2 Wireless Management System
• DMX-512
• 3 DMX control modes: (1, 3 & 5 Ch. modes)
• RDM and RDM Net Compatible
• Primary/Secondary, stand-alone mode
• On-board manual control mode
Electrical:
• Power Draw Total (@ Full On): 320W
• Power Consumption: 2.7A @ 120V/60Hz ; 1.5A @ 220V/50Hz
• Multi-voltage operation: AC 100-240V, 50/60Hz
• Daisy chain: 2 xtures @ 120V; 4 xtures @ 230V
• Fuse protected: 8A/250V
Ambient Temperature Range (For Use):
• -4° ~ 104°F (-20°C ~ 40°C)
Storage Temperature Range:
• -22° ~ 113°F (-30°C ~ 45°C)
Dimensions / Weight:
• Dimensions (LxWxH): 10.66” x 12.92” x 20.68” / 271 x 328 x 525mm
• Weight: 13.23 lbs. / 6kg.
IP Rating / Approvals:
• IP20, CE, FCC, ETL Approved (Pending)
Specications and documentation subject to change without notice.
IP20
4010765
