36
SPECIFICATIONS
Optical:
• 150-Watt Quad RGBA C.O.B. LED (Chip On
Board - Red, Green, Blue & Amber)
• Life expectancy: rated at 50,000 hrs.
• Manual Zoom: 7, 11.5, 16, 20.5 or 25-degrees
• Zoom Ration: 3.3:1
Photometrics:
• 1360 Lux (Zoomed In to 7°)
• 487 Lux (Zoomed Out to 25°)
• CRI: >90
Connections:
• DMX: 5-pin DMX In/Out
• With Wired Digital Communication Network
• Locking power In/Out connections
Control:
• DMX-512 and Aria X2 Wireless DMX / APP
• 6 DMX control modes: (4, 5, 9-A, 9-B, 13, & 15
Ch. modes)
• RDM and RDM Net Compatible
• Primary/Secondary, stand-alone mode
• On-board manual control mode
Features:
• Aria X2 wireless management system built-in
• Linear white color temperature control (2300K ~
9900K)
• Color Temperature Presets (2300K ~ 9900K)
• 4-button DMX menu display on rear panel
• OLED display
• Adjustable latch to manually change beam angle
• Includes gel frame for diffusion filters (Diffusion
filter sold separately)
• 64 Built-in Color Macros
• 13 Built-in Internal Programs
• Strobe Rate: 0.6Hz to 7.5Hz
• Refresh Rate: 3KHz
• Electronic Dimming: 0 - 100%
• 6 Dim Modes
• 4 Dim Curves
• On-board, color balance feature for each color
(RGBA)
Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any
prior written notice.
Electrical:
• Power Draw Total (All LED’s @ Full On): 80W
• Power Consumption: 0.7A @ 120V/60Hz ; 0.4A @
220V/50Hz
• Multi-voltage operation: AC 100-240V, 50/60Hz
• Daisy chain: 11 fixtures @ 120V; 20 fixtures @
230V
• Fuse protected: 3A/250V
Battery:
• Rechargeable Lithium-ion
• Battery Capacity: 12,000mAh
• Battery Voltage: 22.2V
• Charge Time: 6 Hours (To Full)
• Battery operation can be selected by the user for
durations ranging from 5 to 20 hours. 5 Hour dura-
tion will operate at Full Output when battery is fully
charged
• Battery Cycles: 500
• Battery On/Off button
Ambient Temperature Range (For Use):
• -4° ~ 104°F (-20°C ~ 40°C)
Storage Temperature Range:
• -22° ~ 104°F (-30°C ~ 40°C)
Dimensions / Weight:
• Dimensions (LxWxH): 19.4” x 12.8” x 10.7” / 493 x
326 x 271mm
• Weight: 12.79 lbs. / 5.8kg.
IP Rating / Approvals:
• IP20
• CE & FCC
• ETL (Pending)
