Operating Modes:
You can use the P64 LED UV in three ways:
• Sound-Active mode - The unit will react to sound.
• Manual Mode - Maually control the intensity and strobe speed
without using DMX mode.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller such as
as the Elation
® Show Designer™.
Sound Active Mode:
In this mode the P64 LED UV will react to sound.
1. Plug the fixture in and put dipswitch #10 in the “ON” postion.
2. The fixture will now change via sound.
Manual Mode:
1. Plug the fixture in and put dipswitches # 9 and 10 in the “ON”
postion.
2. Dipswitch #1 in the “ON” position will give you an intensity of 25%.
Dipswitch #2 in the “ON” position will give you an intensity of 50%.
Dipswitch #3 in the “ON” position will give you an intensity of 75%.
Dipswitches #1, #2, #3, and #4 in the “ON” positions will give you
an intensity of 100%.
3. Dipswitch #5 in the “ON” position will give you the slowest strobe
speed. Dipswitch #6 in the “ON” position will give you a faster
strobe speed. Dipswitch #7 in the “ON” position will give you an
even faster strobe speed. Dipswitches #5, #6, #7, and #8 in the
“ON” positions will give you the fastest strobe speed.
DMX Mode:
Operating through a DMX controller give the user the freedom to cre-
ate their own programs tailored to their own individual needs. This
function also allows you to use your fixtures as spot lights.
1. This function will allow you to control each individual fixture’s
traits with a standard DMX 512 controller such as the
Elation® Show Designer™ or the Elation® DMX Operator.™
2. The P64 LED UV uses three DMX channels to operate see page
9 for the DMX traits.
3. To run your fixture in DMX mode, plug in the fixture via the XLR
connections to any standard DMX controller. Set your desired
P64 LED UV Operating Instructions
©American DJ Supply® - www.adj.com - P64 LED UV Instruction Manual Page 8
©American DJ Supply® - www.adj.com - P64 LED UV Instruction Manual Page 7
P64 LED UV Photometric Chart
DMX address following the set-up specifications that come with
your DMX controller.
P64 LED UV Operating Instructions
