ADJ Products, LLC - www.adj.com - MOD QW100 User Manual Page 24
ADJ UC IR & Airstream:
This function is used to activate and deactivate the infared sensor. When this function is activated
the unit can be controlled using the ADJ UC IR or Airstream IR app. Please see page 25 for remote
controls and functions.
1. Plug the fixture in and press the MODE button until “OPTION” is displayed.
2. Press the SET UP button until “IR: XX” is displayed.
3. Press the UP or DOWN buttons to either activate the remote function (On) or deactivate it (Off).
MOD QW100 Operating Instructions
MOD QW100 Master-Slave Configuration
Master-Slave Configuration:
This function will allows the user to link units together to run in a Master-Slave set-up. In a Master-
Slave set up. one unit will act as the controlling unit and the others will react to the controlling units
running mode. Any unit can act as a Master or as a Slave, however, only one unit can be programmed
to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain the units via the XLR connectors on the bottom of the unit. Use standard XLR data
cables to link the units together. Remember that the Male XLR connector is the input and the
Female XLR connector is the ouput. The first unit in the chain (master) will use the female XLR
connector only. The last unit in the chain will use the male XLR connector only.
2. Connect the rst “Slave” unit to the “Master.”
3. Set the “Master” unit to a desired mode of operation. On the “Slave” unit’s press the MODE
button until “SLAVE MODE” is displayed. The “Slave” unit(s) will now follow the “Master”.
The body of the MOD QW100 can easily be adjiusted to create a Snoot Effect to eliminate side glare.
Loosen the bracket knobs and slide the innards up and down using the bracket. Find your optimal
setting and tighten the bracket knobs to lock the body in place.
MOD QW100 Snoot Effect
