ADJ Products, LLC - www.adj.com - MOD QA60 User Manual Page 21
MOD QA60 Operating Instructions
The control panel will lock up after 5 seconds of inactivity. Press the MODE button for at least
5 seconds to unlock the contron panel.
LCD Backlight On/Off:
To set the LCD backlight to turn off after 20 seconds, press the MODE button until “OPTION BLGT: XX”
is displayed. “XX” represents the current state. Press the UP or DOWN buttons to set the backlight
to turn “OFF” after 20 seconds or “ON” to stay on at all times.
Operating Modes:
The MOD QA60 has seven operating modes:
• RGBA Dimmer Mode - Choose one of the four colors to remain static or adjust the intensity of
each color to make your desired color.
• Color Change mode - There are 16 color change modes to choose from. In color change mode the
unit will change through the various colors depending on the color change mode that is chosen.
The color change running speed is adjustable.
• Color Fade mode - There are 16 color fade modes to choose from. In color fade mode the unit will
fade through the various colors depending on the color fade mode that is chosen. The fade running
speed is adjustable.
• Auto Run Mode - In Auto Run Mode, the fixture will run a combination of color change and color
fade. The running speed is adjustable.
• Sound Active mode - The unit will react to sound, chasing through the built in programs. There
are 16 sound active modes.
• Static Color Mode - There are 64 colors to choose from.
• DMX control mode - This function will allow you to control each individual fixtures traits with a
standard DMX 512 controller.
DMX Mode:
Operating through a DMX controller gives the user the freedom to create their own programs tailored
to their own individual needs. The MOD QA60 has 5 DMX modes: 4 channel mode, 5 channel mode,
6 channel mode, 9 channel mode, and 10 channel mode. See pages 10-17 for each mode’s DMX
traits.
1. This function will allow you to control each individual fixture’s traits with a standard DMX 512
controller.
2. To run your fixture in DMX mode press the MODE button until “DMX MODE:XXX” is displayed.
“XXX” represents the current displayed DMX address. Use the UP or DOWN buttons to select
your desired DMX address, then press the SETUP button to select your DMX channel mode.
3. Use the UP or DOWN buttons to scroll through the DMX channel modes. The channel modes are
listed below:
• “CHAN: 04” is 4 Channel DMX Mode.
• “CHAN: 05” is 5 Channel DMX Mode.
• “CHAN: 06” is 6 Channel DMX Mode.
• “CHAN: 09” is 9 Channel DMX Mode.
• “CHAN: 10” is 10 Channel DMX Mode.
4. Please see pages 10-17 for DMX values and traits.
5. After you have chosen your desired DMX Channel mode plug in the fixture via the XLR connections
to any standard DMX controller.
