ADJ Products, LLC - www.adj.com - Illusion Dotz 3.3 Instruction Manual Page 16 ADJ Products, LLC - www.adj.com - Illusion Dotz 3.3 Instruction Manual Page 17

2. Press the UP or DOWN buttons until “Status” is displayed, press

ENTER.

3. Press UP or DOWN buttons, until “Tilt Invert” is displayed, and

press ENTER.

4. Either “O” or “On” will be displayed, use the UP and DOWN but-

tons to toggle between.

5. Press ENTER to conrm your selection or press MODE to exit.

PAN DEGREE - With this function you can change the pan degree

from 630 to 540.

1. Press the MODE button to access the main menu. Press the UP or

DOWN buttons so that “Function” is highlighted, then press ENTER.

2. Press the UP or DOWN buttons until “Status” is displayed, press

ENTER.

3. Press UP or DOWN buttons, until “Pan Degree” is displayed, and

press ENTER.

4. Either “540” or “630” will be displayed, use the UP and DOWN

buttons to toggle between.

5. Press ENTER to conrm your selection or press MODE to exit.

FEEDBACK - With this function you can feedback switch the pan

movement or tilt movement.

1. Press the MODE button to access the main menu. Press the UP or

DOWN buttons so that “Function” is highlighted, then press ENTER.

2. Press the UP or DOWN buttons until “Status” is displayed, press

ENTER.

3. Press UP or DOWN buttons, until “Feedback” is displayed, and

press ENTER.

4. Either “O” or “On” will be displayed, use the UP and DOWN but-

tons to toggle between.

5. Press ENTER to conrm your selection or press MODE to exit.

MOVEMENT SPEED - With this function you can set the pan and tilt

Illusion Dotz 3.3 System Menu

movement speed.

1. Press the MODE button to access the main menu. Press the UP or

DOWN buttons so that “Function” is highlighted, then press ENTER.

2. Press the UP or DOWN buttons until “Status” is displayed, press

ENTER.

3. Press UP or DOWN buttons, until “Move Speed” is displayed,

and press ENTER.

4. Either “Speed 1”, “Speed 2”, “Speed 3” or “Speed 4” will be dis-

played, use the UP and DOWN buttons to toggle between.

5. Press ENTER to conrm your selection or press MODE to exit.

MIC SENS - With this function you can set the microphone sensitiv-

ity. The default setting is 70%. You can adjust the sensitivity between

0%-99%

1. Press the MODE button to access the main menu. Press the UP or

DOWN buttons so that “Function” is highlighted, then press ENTER.

2. Press the UP or DOWN buttons until “Status” is displayed, press

ENTER.

3. Press UP or DOWN buttons, until “Mic Sensitivity” is displayed,

and press ENTER.

4. Use the UP and DOWN buttons to adjust the mic sensitivity

between 0%-99%.

5. Press ENTER to conrm your selection or press MODE to exit.

STAND BY - With this function the LEDs and step motors will power

o if there is no DMX signal within 15 mins (factory defualt). Once it

receives a DMX signal, the xture will reset itself.

1. Press the MODE button to access the main menu. Press the UP or

DOWN buttons so that “Function” is highlighted, then press ENTER.

2. Press the UP or DOWN buttons until “Status” is displayed, press

ENTER.

3. Press UP or DOWN buttons, until “Stand By” is displayed, and

press ENTER.

Illusion Dotz 3.3 System Menu
